Specifications
Brand Name :
Olycom
Model Number :
IM-FBS288GW
Certification :
CE RoHS FCC ISO9001
Place of Origin :
Guangdong, China
MOQ :
1pc
Price :
negotiable
Payment Terms :
T/T, PayPal
Supply Ability :
3000pcs/month
Delivery Time :
4~8 working days
Packaging Details :
1 piece in a carton, 0.95kg
Product name :
Optical bypass POE switch
Power input :
48 to 52v DC redundant power
Communication Mode :
350g
Mounting type :
Full-Duplex & Half-Duplex
PoE Ports :
8 ports support poe
Housing :
IP40 Protection Grade, DIN Rail Type
Description

Industrial gigabit 12 port din rial switch managed

optical bypass ethernet switch POE switch


Key Features of 10/100/1000mbps Fiber bypass managed switch

  • 8 x 10/100/1000Mbps Auto-sensing RJ45 ports
  • 2 x2.5G SFP fiber ports, 2 x Bypass ports
  • 6KV Ethernet surge protection, adapt to a harsh outdoor environment
  • Support Auto MDI/MDIX
  • Flow control mode: full duplex with IEEE 802.3x standard, half-duplex with Back pressure standard
  • IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX compliant
  • A store-and-forward switching mechanism
  • Operating environment temperature:-40 ° ~75 ° c


Specification of Gigabit Ethernet Switch

Product Name 10/100/1000Mbps Managed Industrial Fiber Bypass Switch (2F+8TP)
Model No. IM-FBS288GW
Port

2 x 2.5G SFP port

SM:1310nm/1550nm,20Km ;1490nm/1550nm, 40~120Km; MM:1310nm, 2Km; 8x10/100/1000M UTP RJ45(Support MDI/MDIX auto-sensing)
Standard IEEE 802.3, IEEE802.3U, IEEE802.3ab, IEEE802.3z, IEEE802.1d STP, IEEE802.1w RSTP, IEEE802.1s MSTP, ITU-T G.8023 EPR/Y.1344, IEEE802.1Q, IEEE802.1X, IEEE802.3ad, IEEE802.3x, IEEE802.3af, IEEE802.3at, IEEE802.1ad, IEEE802.1p, IEEE802.1ab, IEEE802.3az
VLAND ID 4096
Jumbo Frame 9.6KB
MAC Address Table 8K
Switching features

Transmission mode:storage and forward

System bandwidth:58Gbps (non-traffic jam)

DRAM size: 128M Flash size: 16M
Packet buffer size: 4Mb
Network media

10BASE-T: CAT3, CAT4, CAT5 un-shielded twisted pair(≤100m)

100/1000BASE-TX: CAT5 or above shielded twisted pair(≤100m)

SFP port,transmission distance: 20Km,40Km,60Km,80Km,100Km
LEDs Power, network, fiber, bypass
Power supply

Input voltage: DC 48-52V; No-load power: 5W;

Reverse connection: support
Environment Working Temp:-40°～ 75°C ; Storage Temp:-40°～ 85°C;Working humidity:10%～90%, non-condensing; Storage humidity:10%～95%, non-condensing
Industry Standards

EMI:FCC Part 15 Subpart B Class A,EN 55022 Class A

EMS:EN 61000-4-2 (ESD) Level 3,EN 61000-4-3 (RS) Level 3, EN 61000-4-4 (EFT) Level 3, EN 61000-4-5 (Surge) Level 3, EN 61000-4-6 (CS) Level 3, EN 61000-4-8; Traffic Control:NEMA-TS2; Vibration:IEC 60068-2-6; Freefall:IEC 60068-2-32; Shock:IEC 60068-2-27; Rail Traffic:EN 50121-4
Safety CE Mark ,commercial ; CE/LVD EN60950
Mechanical information

Shell:Corrugated metal shell; Safety class:IP40;

Dimension:158 x 114.8 x 60mm;
Warranty 3 years


Connection diagram of Optical Fiber Bypass

Industrial Gigabit 12 Port Din Rial Switch Managed Optical Bypass Ethernet POE Switch



About Olycom

  • Olycom manufactures and markets fiber optic connectivity devices.
  • Olycom provides solutions and services of industrial fiber switch, fiber to copper media conversion, Ethernet networking, and CCTV video surveillance.
  • Olycom currently focuses on

Industrial Networking
Optical Bypass
WDM Equipment
Optical Monitoring Systems
POE++


FAQ

1. What is the power input?

A: For non-PoE managed switches, it receives DC12V~52V, for PoE managed switches, it receives DC48V~52V.

All the models support redundant input.

2. What is the PoE budget?

A: The standard PoE output is 30W per port.

Take IM-FP288GW for example, it has 8 PoE ports, so the budget is 30W/port*8 ports=240W.

We can also support 60W output if it is required, please confirm with us.

3. How can I install the device?

A: Each model in this series supports DIN35/Wall mounting.

It requires necessary accessories in installation like screws, mounting kit etc., some of them are included in the packing box, some are not.

4. Does your switch support 155Mb/s tranceivers?

A: Yes, the optical speed is 100M/1000M/2500M. Please just configure 100M speed in the management interface, megabit modules are working.

5. If possible to write the label as I want?

A: Yes, please just send the content and format, and we will print a sample piece for your confirmation.

The label is usually attached to the side panel.
