400G Coherent CFP2 Card 4*QSFP28 OTU Service Board For Tunable C-Band 96-Wave Transmission
400G Coherent CFP2 Card 4*QSFP28 OTU Service Board For Tunable C-Band 96-Wave Transmission
400G Coherent CFP2 Card 4*QSFP28 OTU Service Board For Tunable C-Band 96-Wave Transmission
400G Coherent CFP2 Card 4*QSFP28 OTU Service Board For Tunable C-Band 96-Wave Transmission
400G Coherent CFP2 Card 4*QSFP28 OTU Service Board For Tunable C-Band 96-Wave Transmission
400G Coherent CFP2 Card 4*QSFP28 OTU Service Board For Tunable C-Band 96-Wave Transmission
Specifications
Brand Name :
Olycom
Model Number :
OM3800-400G
Certification :
CE RoHS FCC ISO9001
Place of Origin :
Shenzhen, China
MOQ :
1pc
Price :
negotiable
Payment Terms :
T/T, PayPal
Supply Ability :
1500pcs/month
Delivery Time :
4~7 days
Packaging Details :
1 piece in a box, 2Kg G.W.
Product Name :
400G OTU service card
Connector :
1*CFP2+4*QSFP28
Max distance :
1200KM
Wavelength :
96ch, C-band
Description

Olycom 400G Muxponder CFP 2 DWDM Optical Transport Unit

Introduction

  1. The 400G OTU service board supports four 100G service accesses, adopts advanced technologies such as PDM-QPSK modulation and coherent reception, and overcomes the transmission physical effects of high-speed transmission systems on OSNR requirements, CD tolerance, PMD tolerance, and nonlinearity.
  2. It can realize 400G business over 1,200 kilometers of non-relay transmission, and the line side interface supports C-band 96-wave (50GHz) tunable.

Product Parameters

Function Description
Interface

1. Client-side interfaces: 4, pluggable based on QSFP28

2. Line side interface: 1, based on CFP2 pluggable, coherent PDM-QPSK
Line mode Support transparent transmission of 1 400G service, which can convert 4 channels of 100G service optical signals on the client side into 1 channel of 400G rate DWDM standard wavelength optical signals
Repeater mode Support 400G wavelength electrical relay
Support business type

100GE

OTU4
WDM technology Support DWDM: C-band 50GHz 96 waves tunable
FEC technology Support SDFEC
Number of occupied slots Support OM3800 full series chassis, occupying 2 slots, (1U)
Network management function

l Support real-time monitoring of port working status, including: transmit optical power, receive optical power, temperature, etc.

l Support port loopback function and port shutdown function
Max power consumption 50W (including optical module)
MTBF ＞100,000 hours

Product Interface

400G Coherent CFP2 Card 4*QSFP28 OTU Service Board For Tunable C-Band 96-Wave Transmission

Item Interface Description
CFP2 interface Tx Module output optical interface
Rx Module input optical interface
QSFP28interface QSFP28 Module input and output optical interface
Interface Item Description
RUN OTU card operation indicator

On, OTU operation is normal

Off, OTU operation failure
QR1 Branch 1 module side receiving light indicator

On, light receiving is normal

Off, light receiving is abnormal
QR2 Branch 2 module side receiving light indicator

On, light receiving is normal

Off, light receiving is abnormal
QR3 Branch 3 module side light receiving indicator

On, light receiving is normal

Off, light receiving is abnormal
QR4 Branch 4 module side light receiving indicator

On, light receiving is normal

Off, light receiving is abnormal
CR Line-side module light receiving indicator

On, light receiving is normal

Off, light receiving is abnormal

Diagram

400G Coherent CFP2 Card 4*QSFP28 OTU Service Board For Tunable C-Band 96-Wave Transmission

OTU card management interface

400G Coherent CFP2 Card 4*QSFP28 OTU Service Board For Tunable C-Band 96-Wave Transmission

  • Online real-time monitoring of the working status of the business disk
  • On-line monitoring module link status, port link status
  • Real-time monitoring module transmit and receive light power, current working rate
  • Support real-time reading of optical module DDM information
  • Support reading module wavelength and channel information

OTU Card Setup

1. Device receiving power alarm threshold setting

The receiving power alarm threshold of the optical module can be set through the network management. When the receiving power is lower than the threshold, the device will prompt an alarm and notify the maintenance personnel to pay attention without affecting the business

2. ALS mode setting

The ALS function can be set through the network management system. When the ALS function is enabled, the optical module itself cannot receive light, and the side optical module itself does not emit light.

400G Coherent CFP2 Card 4*QSFP28 OTU Service Board For Tunable C-Band 96-Wave Transmission

400G Coherent CFP2 Card 4*QSFP28 OTU Service Board For Tunable C-Band 96-Wave Transmission
