Hot Dipped Galvanized Concertina Razor Barbed Wire 960mm BTO-12
Hot Dipped Galvanized Concertina Razor Barbed Wire 960mm BTO-12
Hot Dipped Galvanized Concertina Razor Barbed Wire 960mm BTO-12
Hot Dipped Galvanized Concertina Razor Barbed Wire 960mm BTO-12
Specifications
Brand Name :
QiJie
Model Number :
SGS2019025
Certification :
Certification ISO2019025
Place of Origin :
HeBei,China
MOQ :
1 rolls
Price :
Discuss
Payment Terms :
30%TT
Supply Ability :
1500 Roll/Rolls per Week
Delivery Time :
within 7-30 days
Packaging Details :
Wooden carton
Material :
galvanized steel sheet
application :
Protecting Mesh, Fence Mesh
Finish :
Hot Dipped Galvanized
Coil Outside Diameter :
960mm
extended length :
15m
name :
concertina razor barbed wire
Description

Galvanized Razor Barbed Wire Concertian Razor Wire Coil Razor Wire

Hot Dipped Galvanized Concetrtina Razor Barbed Wire Introduction
Razor barbed wire is composed of blade and core wire. The blade is made of galvanized steel sheet or stainless steel sheet, which is punched into blade shape. And the core wire is high tension galvanized iron wire, or stainless steel wire, plastic barbed wire. Razor barbed wire is easily and expediently installation.
Sorts of the Hot Dipped Galvanized Concetrtina Razor Barbed Wire:
1). Single loop razor wire (Coin type)
2). Double loop concertina razor wire (Cross type)
3). Flat razor wire (Flat/Ring type)
4). Welded razor wire mesh panel (Welded type)
Cross type (double loops) razor barbed wire is also called concertina barbed wire. The two contiguous razor barbed wires cross and fastened by iron clips. The steel plate is punched and cut into sharp blade strip and enwrapped the mid-carton steel wire (core wire). It's widely used in the airport, prison, railway, etc.



Hot Dipped Galvanized Concertina Razor Barbed Wire 960mm BTO-12


Hot Dipped Galvanized Concertina Razor Barbed Wire 960mm BTO-12


Hot Dipped Galvanized Concertina Razor Barbed Wire 960mm BTO-12

Razor Blade Specification:
Reference Number Blade Style Thickness Wire Dia Barb
Length		 Barb
Width		 Barb
spacing
BTO-12 Hot Dipped Galvanized Concertina Razor Barbed Wire 960mm BTO-12 0.5±0.05 2.5±0.1 12±1 13±1 26±1
BTO-18 Hot Dipped Galvanized Concertina Razor Barbed Wire 960mm BTO-12 0.5±0.05 2.5±0.1 18±1 15±1 33±1
BTO-22 Hot Dipped Galvanized Concertina Razor Barbed Wire 960mm BTO-12 0.5±0.05 2.5±0.1 22±1 15±1 34±1
CBT-65 Hot Dipped Galvanized Concertina Razor Barbed Wire 960mm BTO-12 0.6±0.05 2.5±0.1 65±2 21±1 100±2
Barbed Tape Concertina (BTC);Barbed Tape Obstacle (BTO)
Standard materials are either galvanized or stainless steel.
Standard packages products are shown in the tables above, special specifications available on request.


Specifications:

Reference number Thickness Wire Dia Barb length Barb width Barb spacing
BTO-10 0.5±0.05 2.5±0.1 10±1 13±1 26±1
BTO-12 0.5±0.05 2.5±0.1 12±1 15±1 26±1
BTO-18 0.5±0.05 2.5±0.1 18±1 15±1 33±1
BTO-22 0.5±0.05 2.5±0.1 22±1 15±1 34±1
BTO-28 0.5±0.05 2.5 28 15 45±1
BTO-30 0.5±0.05 2.5 30 18 45±1
CBT-60 0.5±0.05 2.5±0.1 60±2 32±1 100±2
CBT-65 0.5±0.05 2.5±0.1 65±2 21±1 100±2

Specification of concertina razor wire
Outside diameter No.of loops Standard length per coil Type Notes
450mm 33 7-8M CBT-60.65 Single coil
500mm 56 12-13m CBT-60.65 Single coil
700mm 56 13-14m CBT-60.65 Single coil
960mm 56 14-15m CBT-60.65 Single coil
450mm 56 8-9m(3 clips) CBT-10.10.18.22.28.30 Cross type
500mm 56 9-10m(3 clips) CBT-10.10.18.22.28.30 Cross type
600mm 56 10-11m(3 clips) CBT-10.10.18.22.28.30 Cross type
600mm 56 8-10m(5clips) CBT-10.10.18.22.28.30 Cross type
700mm 56 10-12m(5 clips) CBT-10.10.18.22.28.30 Cross type
800mm 56 11-13m(5 clips) CBT-10.10.18.22.28.30 Cross type
900mm 56 12-14m(5 clips) CBT-10.10.18.22.28.30 Cross type
960mm 56 13-15m(5clips) CBT-10.10.18.22.28.30 Cross type
980mm 56 14-16m(5 clips) CBT-10.10.18.22.28.30 Cross type


Hot Dipped Galvanized Concertina Razor Barbed Wire 960mm BTO-12


Hot Dipped Galvanized Concertina Razor Barbed Wire 960mm BTO-12
