8mm Tec Sieve Architectural Woven Metal Mesh Multi Barrette Weave / Cable Mesh System
8mm Tec Sieve Architectural Woven Metal Mesh Multi Barrette Weave / Cable Mesh System
8mm Tec Sieve Architectural Woven Metal Mesh Multi Barrette Weave / Cable Mesh System
8mm Tec Sieve Architectural Woven Metal Mesh Multi Barrette Weave / Cable Mesh System
Specifications
Brand Name :
Qijie
Place of Origin :
China
MOQ :
10meters
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
100meters/month
Delivery Time :
15-18days
Packaging Details :
pallets
Connection :
Springs & rods
Dimesion :
Wide max 4m, Length max 8m
Durability :
Long Lasting
Flat Pitch :
8.5mm
Flexibility :
Easy to Shape
Length :
30 m
Material :
Stainless Steel
Mesh Count :
10 x 10
Mesh Thickness :
4.4mm
Opening Area :
27.3%
Shape :
In rolls
Thickness :
8mm
Type :
Architectural Wire Mesh--Tec-Sieve
Weave Type :
Plain Weave
Width :
1 m
Description

Architectural Wire Mesh--Tec-Sieve Multi-Barrette Weave/Cable Mesh System

Tec-Sieve multi-barrette weave/cable mesh system consists of Tec-Sieve multi-barrette weave (cabled woven) mesh panels and Tec-Sieve mounting devices.
Tec-Sieve multi-barrette weave mesh panels, also known as cable mesh panels, are made from stainless steel solid rods crosswise and stainless steel cable clusters lengthwise. The cable clusters create flexibility lengthwise and the solid rods create stability crosswise so that the metal wire mesh element can be easily tensioned in one direction while remaining rigid in the other direction. Tec-Sieve multi-barrette is well suited for exterior applications where an aesthetically pleasing yet protective facade is required.
Tec-Sieve multi-barrette weave mesh panels can be woven up to 8 meters in width. We can also cut the wire mesh element to your desirable size and shape.
Tec-Sieve mounting devices are actually a complete set of tensioning devices, which include woven-in stainless steel round bars that are in the place of a number of weft wires (solid rods) in the multi-barrette weave metal fabric, stainless steel eyebolts, stainless steel springs and nuts & washers.
8mm Tec Sieve Architectural Woven Metal Mesh Multi Barrette Weave / Cable Mesh System8mm Tec Sieve Architectural Woven Metal Mesh Multi Barrette Weave / Cable Mesh System
8mm Tec Sieve Architectural Woven Metal Mesh Multi Barrette Weave / Cable Mesh System

SPECIFICATION SHEET OF FREQUENTLY MADE MULTI-BARRETTE WEAVE MESH PANELS

Model Material Cable Diameter Cable Pitch Solid Rod Diameter Solid Rod Pitch Weight
TS-4263 Stainless Steel 304, 316 or 316L 0.75mmX4 26.4mm 1.5mm 3mm Ca. 5.3kg/m²
TS-4364 Stainless Steel 304, 316 or 316L 1mmX4 36mm 2mm 4mm Ca.7kg/m²
TS-4506 Stainless Steel 304, 316 or 316L 2mmX4 50mm 3mm 6mm Ca.11.56kg/m²
TS-3411 Stainless Steel 304, 316 or 316L 3mmX3 40mm 3mm 11mm Ca.9.5kg/m²
TS-2415 Stainless Steel 304, 316 or 316L 2.75mmX2 40mm 4mm 14.5mm Ca.9.41kg/m²
TS-3810 Stainless Steel 304, 316 or 316L 2mmX3 80mm 3mm 10mm Ca.6.6kg/m²
TS-3865 Stainless Steel 304, 316 or 316L 2mmX3 80mm 3mm 6.5mm Ca.9.74kg/m²
TS-1326 Stainless Steel 304, 316 or 316L 1.6mmX1 3.2mm 1.2mm 6mm Ca.5kg/m²
TS-1315 Stainless Steel 304, 316 or 316L 2mmX1 3.1mm 1.2mm 5mm Ca.10kg/m²
TS-1056 Stainless Steel 304, 316 or 316L 2.5mmX1 5mm 2mm 6mm Ca.12.2kg/m²
TS-1068 Stainless Steel 304, 316 or 316L 2.5mmX1 6mm 2mm 8mm Ca.9.8kg/m²
TS-3352 Stainless Steel 304, 316 or 316L 0.45mmX3 3.5mm 0.5mm 1.6mm Ca.2.1kg/m²
TS-3352PC Phosphorous Copper 0.45mmX3 3.5mm 0.5mm 1.6mm Ca.2.3kg/m²
Note:
1. Some specifications of our multi-barrette weave mesh panels can be woven through the use of
phosphorous copper materials, instead of stainless steel, like TS-3352;
2. If you need any other specification not shown in this sheet, please feel free to email us asking for help from our engineer.

TYPICAL APPLICATIONS
Facades Car Parks
Sunscreens Roller Shutters
Suspended Ceilings Floor Coverings
Wall Cladding Column Cladding
Partition Screens Projection Screens
Staircases Elevator cabins
Balustrades ......
