Product Description
Wire diameter(mm) | 3.0/3.5/3.8/4.0 | |||
Mesh opening(mm) | 60*150, 60*200, 75*75, 75*150, 75*200, 75*300, 100*300mm | |||
H*W(mm) | 1800*2400, 1800*2500, 2100*2400, 2100*2500mm | |||
Frame(mm) | ∅32, ∅40, ∅42, ∅48mm | |||
Plastic Base Block | 660(L)*220(W)*150(H)mm | |||
Color Available | Yellow, green and grey | |||
Surface Treatment: Hot dipped galvanization before welding with silver protecting on the weld joints or hot dipped galvanized after welding. |
Wire diameter(mm) | 3.0/3.5/3.8/4.0 | |||
Mesh opening(mm) | 60*150, 60*200, 75*75, 75*150, 75*200, 75*300, 100*300mm | |||
H*W(mm) | 1500*3000, 1800*3000, 2000*3000mm | |||
Frame(mm) | 20*20mm, 25*25mm | |||
Steel Base Block | 762*100*5mm thk | |||
Color Available | Red, blue, yellow, green and grey | |||
Surface Treatment: Galvanized and Electrostatic polyester power coated or hot dipped galvanized after welding. |
