400KG 1700MM Semi Electric Pallet Stacker High Ability Material Light Weight
400KG 1700MM Semi Electric Pallet Stacker High Ability Material Light Weight
400KG 1700MM Semi Electric Pallet Stacker High Ability Material Light Weight
400KG 1700MM Semi Electric Pallet Stacker High Ability Material Light Weight
400KG 1700MM Semi Electric Pallet Stacker High Ability Material Light Weight
400KG 1700MM Semi Electric Pallet Stacker High Ability Material Light Weight
400KG 1700MM Semi Electric Pallet Stacker High Ability Material Light Weight
400KG 1700MM Semi Electric Pallet Stacker High Ability Material Light Weight
Specifications
Brand Name :
Haizhili
Model Number :
BDDJ1700
Certification :
CE, ISO
Place of Origin :
Hubei Province
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
500 sets per month
Delivery Time :
10 - 20 working days
Packaging Details :
To be packed in a iron pallet.
Type :
Light weight semi electric stacker
Load capacity :
400kg
Machine weight :
118kg
Fork length :
610mm
Fork width :
550m
Table size :
610*580mm
Lifting motor :
DC12V/0.5KW
Storage battery :
60ah
Charge input voltage :
220/110V
Min lifting height :
90mm
Description

400KG 1700MM High Ability Material Platform Semi Electric Pallet Stacker

Quick detail

1. Load capacity: 400kg

2. Lifting height: 1700mm

3. Built in overload value

4. Light vehicle structure

Specification of Semi Electric Pallet Stacker:

Model
BDDJ1300
BDDJ1500
BDDJ1700
Load capacity(KG)
400KG(800LB)
400KG(800LB)
400KG(800LB)
Lowest height(mm)
90
90
90
Max.height(mm)
1300
1500
1700
Fork length(mm)
610
610
610
Fork width(mm)
550
550
550
Table dimensions(mm)
610x580
610x580
610x580
Handle length(mm)
1150
1150
1150
Overall length(mm)
1000
1000
1000
Overall height(mm)
1565
1765
1965
Net weight(kg)
108
111
118
Voltage(V)
12
12
12
Power(kw)
0.5
0.5
0.5
Storage battery
60
60
60
Charge input voltage(V)
220/110
220/110
220/110

Feature of Semi Electric Pallet Stacker:

1. With chain cover design, Rust-proof and dustproof.

2. Hand spin control Knob automatic homing The operation is simple.

3. Extended pedal design rise more convenient.

4. Configuring butter mouth, You can beat grease lubrication.

5. Both steering wheel brake configuration.

6. Extra strong pure steel roller, wear-resisting compressive strength.

Description of Semi Electric Pallet Stacker:

1.Low profile forks can lift pallet easily.

2.Noise-free caster as option.

3.Adjustable fork as optional.

4.Option platform.

Simple and Easy Operation :

1. Lifting movement via collapsible foot pedal .

2. Sensitive lowering through sinking valve .

3. Hand push drive.

4. Overload protection via pressure valve

Safe Operation and secure Working Conditions

Stable chassis with 2 frame rollers and 2 steering rollers

Long Service Lift :
