Network Security Firewall Fanless Mini Pc Pfsense 6 Gigabit LAN Quad Core E3845 J1900
Network Security Firewall Fanless Mini Pc Pfsense 6 Gigabit LAN Quad Core E3845 J1900
Network Security Firewall Fanless Mini Pc Pfsense 6 Gigabit LAN Quad Core E3845 J1900
Network Security Firewall Fanless Mini Pc Pfsense 6 Gigabit LAN Quad Core E3845 J1900
Specifications
Brand Name :
VEGASHINE / OEM
Model Number :
PF11106003-BT-E3845
Place of Origin :
China
MOQ :
1 unit
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1000 units per Month
Delivery Time :
3 to 10 work days
Packaging Details :
Carton
Chassis :
Aluminium chassis
Dimension :
134*126*40.6 mm
Chassis color :
Black
CPU :
Integrated Intel® Bay Trail J1800 / J1900 / N2806 /E3845
RAM :
1*DDR3L
Gigabit LAN :
6* Gigabit LAN
COM port :
1* CISCO standard RS232 serial
Description

6 Gigabit LAN Network security firewall appliance quad core E3845 / J1900 pFsense fanless mini PC

Notice :

When you inquiry , you can choose the following Model :

PF11106003-BT-J1800 Integrated Celeron® Bay Trail J1800 dual core 2 threads 2.41~2.58Ghz processor

PF11106003-BT-J1900 Integrated Celeron® Bay Trail J1900 quad core 4 threads 2.0~2.42 Ghz processor

PF11106003-BT-N2806 Integrated Celeron® Bay Trail N2806 dual core 2 threads 1.6~2.0Ghz processor

PF11106003-BT-E3845 Integrated Atom® Bay Trail E3845 quad core 4 threads 1.91Ghz processor

6 Gigabit LAN Network security firewall appliance quad core E3845 / J1900 pFsense fanless mini PC

Key Features

Integrated Intel® Bay Trail J1800 / J1900 / N2806 /E3845

Single channel DDR3L 1066/1333MHz max up to 8GB

1* SATAIII ports

1*Mini-PCIe M-SATA Scoket

Onboard 32/64/128G EMMC chip(Optional);

1*HDMI

1*USB3.0

1*USB2.0

1*RJ45 COM

6*RJ45 Gigabit Lan

Single input DC power,DC12-19V,+/-5%

Dimension: 134*126*40.6 mm

Fanless Design,Noiseless design

Aluminium chassis

Specifications

Chassis Color Black
Dimension 134*126*40.6 mm
Material High-quality pure aluminum mini pc case
Platform Processor Integrated Intel® Bay Trail J1800 / J1900 / N2806 /E3845 Processor
Chipset Baytrail-D/I/M processor
Video Graphics

Intel HD Graphics

1*H-D-M-I Resolution maximum 1920x1080
Memory Technology framework Single channel DDR3L 1066/1333MHz max to 8GB
RAM socket 1 *DDR3 SODIMM 204 Socket
Storage SATA 1* SATAIII ports,Maximum transmission rate to 6gb/s
M-SATA 1*Mini-PCIe M-SATA Scoket,support SANDISK Protocol,Maximum transmission rate 6gb/s
eMMC Support 32/64/128G(optional)
Network Ethernet 6*Intel I211AT or Intel I210 Gigabit LAN(optional)
WiFi NA
Input/Output Interface Ports

1*HDMI

1*USB3.0

1*USB2.0

6*LAN

1*Quick Power On button with indicator

1*Restart button

1*DC

1*Power Indicator

1*Hard disk indicator

1*RJ45 port RS232 or RS485(optional)
Expansion Mini PCIe 1*Mini-PCIe socket,support PCIE and USB Signal equipment
Cooling Fanless Design,Noiseless design
Power Supply Power type Single input DC power,DC12-19V,+/-5%
WORKING ENVIRONMENT Operating temperature -20℃ ~ +60℃
storage temperature -40℃ ~ +85℃
Working humidity 0% ~ 90% relative humidity, no condensation
Storage humidity 0% ~ 90% relative humidity, no condensation
Operate System Support Win 7/8/10, Linux, Pfsense, Mikrotik, iKuai, WayOS, LEDE, Openwrt, Panabit, Smart6 , Ubuntu , Centos etc.

About RMA

1--Warranty 1 year

2--If buyer confirm the item can`t work well due to the non-artificial factors,buyer can return it to our company. Buyers should keep it with proper packaging.

3--Buyers are responsible for return to china freight cost .

4--Seller will repair item and ship the repaired one to buyer,seller will pay the shipping cost from China to Buyer address.

5--Please contact us firstly before returning defective goods by email.

Shipping

Support DHL / UPS / FEDEX / air shipping deliver time 4 to 8 business days

Support Sea shipping for Batch order deliver time 25 to 50 days
