Specifications
Brand Name :
VEGASHINE / OEM
Model Number :
ITX-P6821D-ELK
Place of Origin :
Shenzhen China
MOQ :
1 unit
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1000 units per Month
Delivery Time :
3 to 10 work days
Packaging Details :
Carton
CPU :
Intel Elkhart Lake series processor X6413E quad cores 4 threads 1.5Ghz
RAM :
2*DDR4 SO-DIMM Ram socket, Max support 32GB
Ethernet :
1*Gigabit LAN
Display :
LVDS/EDP+VGA+HDMI Synchronous or asynchronous display
COM :
6*COM (4*RS-232, 2*RS422/485)
Size :
170 x 170 mm
Power :
Single DC 12V power supply
Description

Atom® Elkhart Lake J6413 X6413E motherboard for all in one PC 6COM support TPM2.0

Notice:

When you inquiry , you can choose the following Model

ITX-P6821D-ELK-J6413 onboard Intel Elkhart Lake series processor J6413 quad cores 4 threads 1.8~3.0Ghz

ITX-P6821D-ELK-X6413E onboard Intel Elkhart Lake series processor X6413E quad cores 4 threads 1.5~3.0Ghz


ATOM ® Elkhart Lake processor J6413 X6413E motherboard for all in one PC 6COM support TPM2.0


Key features

Intel Elkhart Lake series processor X6413E quad cores 4 threads 1.5~3.0Ghz
Support 2*DDR4 SO-DIMM Ram socket, Max support 32GB
Intel® UHD Graphics for 10th Gen Intel® Processors
Support LVDS/EDP+VGA,LVDS/EDP+HDMI,HDMI+VGA Synchronous or asynchronous display
Support LVDS/EDP+VGA+HDMI Synchronous or asynchronous display
4*RS-232, 2*RS422/485
1*Gigabit LAN
8*USB2.0
2*USB3.1
1* M.2 KEY-E port
2*Standard SATAIII Ports
Onboard SSD 32G/64G/128G
Mini-itx 170 x 170 mm
DC 12V Power supply

Specifications

ProcessorCPU

Adopt Intel Elkhart Lake series processor
Intel Elkhart Lake series processor X6413E quad cores 4 threads 1.5Ghz
Burst Frequency 3.0 Ghz

CPU packageBGA
ChipsetIntel Elkhart Lake series processor
BIOSEFI BIOS
RamTechnology ArchitectureDual channel DDR4 2133/2400/2666/3200MHz
socket2*DDR4 SO-DIMM Ram socket,Max support 32GB
VideoGraphics controllerIntegrated INTEL UHD Core graphics card, graphics card model is related to CPU
Dual LVDS and EDPLVDS supports dual-channel 24-bit output, the highest resolution 1920 x 1200 EDP supports a maximum resolution of 4096*2304@60Hz (LVDS and EDP display can only choose one)
HDMIHDMI2.0 support highest resolution 4096*2160@60Hz
Dual displayLVDS/EDP+VGA,LVDS/EDP+HDMI,HDMI+VGA Synchronous or asynchronous display
Three displayLVDS/EDP+VGA+HDMI Synchronous or asynchronous display
I/O panelPorts1*DC 1*VGA 1*HDMI 2*LAN 2*USB3.1 1*LINE OUT 1*MIC
NetworkController2*intel I211 or I210 lan card(When the I/O interface is 4 USB, there is only one Intel I211AT or I210 network card)
AudioControllerRealtek HD ALC662 audio decoding (left and right channel + microphone)
Super I/OControllerIT8786E
Hardware controllerWatch-dog timer0-255 seconds, providing a watchdog routine
CoolerAluminum fan heater (supports automatic and manual fan speed adjustment)
Output/input PortsUSB2*USB3.1(USB3.1 GEN2 Backward compatible ),8*USB2.0
Serial port4*RS-232, 2*RS422/485(Can choose 6*RS232 or 5*RS232 and 1*RS422/RS485),RS485supports automatic flow control
PS/21*PS/2 pin header (support PS/2 Keyboard mouse)
Touch panelSupport touch screen(4wire 5wire 8wire ,When the touch screen is available,USB3 pin header only can use one)
GPIO8-bit, providing routines, freely defined input/output, 3.3V@24mA level
Expansion busM.21*KEY-E port,support PCIE protocol,USB protocol WIFI module is available (only one set of JUSB2 pins is available for USB signal)
Mini-PCle1 Mini-PCIe slot, supporting PCIe and USB devices (only one set of JUSB2 pins is available when there is a USB signal)
storageSATA2*standard SATAIII port, maximum transfer rate 6Gb/s(SATA1 and MSATA pick one of two,SATA2and onboard SSD pick one of two)
M-SATA1*M-SATA Scoket,support SANDISK protocol, maximum transfer rate 6gb/s(with SATA1 pick one of two)
Onboard SSDOnboard SSD 32G/64G/128G(Onboard SSD and SATA2 pick one of two)
Power supplyPower supplySingle input DC power supply,DC12V 7A,+/-5%
WORKING ENVIRONMET　-20℃ ~ +60℃
Working temperature
Storage temperature-40℃ ~ +85℃
Working humidity0% ~ 90%(non-condensing)
Storage humidity0% ~ 90%(non-condensing)
SystemOSWindows10 Linux
SizeSize170 x 170 mm
Weight0.5KG
