Meeting E-Whiteboard DC12-19VOPS PC Motherboard MINI DP Intel® Comet Lake 5205U
Meeting E-Whiteboard DC12-19VOPS PC Motherboard MINI DP Intel® Comet Lake 5205U
Meeting E-Whiteboard DC12-19VOPS PC Motherboard MINI DP Intel® Comet Lake 5205U
Meeting E-Whiteboard DC12-19VOPS PC Motherboard MINI DP Intel® Comet Lake 5205U
Specifications
Brand Name :
VEGASHINE / OEM
Model Number :
OPS-PM10C-5205U
Place of Origin :
Shenzhen China
MOQ :
1 unit
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1000 units per Month
Delivery Time :
3 to 10 work days
Packaging Details :
Carton
CPU :
Intel® Core™ Comet Lake 5205U Dual cores 2 threads 1.9Ghz
RAM :
1*DDR4 SODIMM 260 Socket
Ethernet :
1*Gigabit LAN
Display :
VGA / MINI DP
COM :
1* RS232
NGFF_SSD :
1*NGFF_SSD Port
Power :
DC12-19V, +/-5%
Size :
165*114.2 mm
Description

Intel® Core™ Comet Lake 5205U OPS PC motherboard MINI DP for meeting Electronic Whiteboard DC12-19V

Key features

Integrated Intel® Core™ Comet Lake 5205U Dual cores 2 threads 1.9Ghz

1*DDR4 SODIMM 260 Socket

Onboard 1*Gigabit Ethernet Port

1*SATA3.0

1*NGFF_SSD

1*Gigabit LAN

1*VGA, MINI DP

2*USB3.1

2*USB2.0

1*RS-232

Support OPS Expansion

Size: 165*114.2 mm

Single input DC power supply, DC12-19V, +/-5%

Specifications

Processor CPU Integrated Intel® Core™ Comet Lake 5205U Dual cores 2 threads 1.9Ghz
CPU package BGA
chipset Support Comet Lake-U Serial processor
BIOS EFI BIOS
Memory Technology Architecture Single channel DDR4 2133/2400/2666MHz
socket 1*DDR4 SODIMM 260 Socket
Video Graphic controller Intel UHD Graphics ,graphics models related to CPU
MINI DP MINI DP support max resolution 4096x2304 60HZ
HDMI support max resolution(HDMI2.0)4096*2304@60HZ Support 4K display output
Dual display HDMI+MINI DP sync or asynchronous display
I/O back panel Port 1*MINI DP,1*HDMI,1*LAN,2*USB3.1( GEN2),2*USB2.0,1*MIC-OUT/LINE-OUT,1*1*Power indicator, 1* hard disk indicator,1*switch button,
1*1*TYPE-C(USB3.1 GEN2 TYPE-C interface only supports data transmission)
Internet controller 1*Intel I219-LM Gigabit Ethernet, RJ45 interface
Audio controller Realtek HD ALC662 audio decoding (left and right channel + microphone)
Super I/O controller IT8163E
Hardware control Watchdog timer 0-255 seconds to provide watchdog routines
Cooler Aluminum fan heatsink
Input / output interface USB

2*USB3.1( GEN2)

2*USB2.0
Com port 1*RS-232
Expansion bus NGFF 1*NGFF port(KEY E)
NGFF 1*NGFF port support 3G/4G module
storage SATA 1*standard SATAIII port,maximum transfer rate of 6Gb/s( with SATA_HDD choose one,default is SATA_HDD)
SATA_HDD 1*SATA_HDD hard disk interface,maximum transfer rate of 6Gb/s(with SATA choose one)
NGFF 1*NGFF_SSD port
Power type Power type Single input DC power supply,DC12-19V,+/-5%
Working temperature Working temperature -20℃ ~ +60℃
Storage temperature -40℃ ~ +85℃
Operating humidity 0% ~ 90% relative humidity, no condensation
Storage humidity 0% ~ 90% relative humidity, no condensation
System 　 WIN10 Linux
Size Size 165*114.2 mm
Weight 0.5KG
System 　 Windows10 Linux
Size Size 165*114.2mm
Weight 0.5KG


Meeting E-Whiteboard DC12-19VOPS PC Motherboard MINI DP Intel® Comet Lake 5205U

Meeting E-Whiteboard DC12-19VOPS PC Motherboard MINI DP Intel® Comet Lake 5205U

Meeting E-Whiteboard DC12-19VOPS PC Motherboard MINI DP Intel® Comet Lake 5205U

Meeting E-Whiteboard DC12-19VOPS PC Motherboard MINI DP Intel® Comet Lake 5205U
