Mini 4K HDMI Optical Transceiver with support for HDMI 1.4a and HDCP 1.2
Mini 4K HDMI Optical Transceiver with support for HDMI 1.4a and HDCP 1.2
Mini 4K HDMI Optical Transceiver with support for HDMI 1.4a and HDCP 1.2
Mini 4K HDMI Optical Transceiver with support for HDMI 1.4a and HDCP 1.2
Mini 4K HDMI Optical Transceiver with support for HDMI 1.4a and HDCP 1.2
Mini 4K HDMI Optical Transceiver with support for HDMI 1.4a and HDCP 1.2
Mini 4K HDMI Optical Transceiver with support for HDMI 1.4a and HDCP 1.2
Mini 4K HDMI Optical Transceiver with support for HDMI 1.4a and HDCP 1.2
Specifications
Brand Name :
E-link
Model Number :
LNK-106M
Certification :
Iso9001, CE, ROHS, FCC
Place of Origin :
China
MOQ :
1 pair
Price :
negotiate
Payment Terms :
T/T, Western Union, MoneyGram, PayPal
Supply Ability :
1000PCS/Month
Delivery Time :
3-5 working days
Packaging Details :
HDMI Fiber Extender Standard Carton Packaging
Dynamic EDID :
Plug & Play, no need to learn
Website Specifications :
Single-mode single fiber
Fiber Connector :
Double LC Receptacle
Operating Temperature :
0°C to + 50°C
Operation Voltage :
5VDC
Dimension (WxDxH) :
3.15 x 0.79 x 0.35 in (80x20x9mm)
Description

Mini 4K HDMI Optical Transceiver with support for HDMI 1.4a and HDCP 1.2

Model :LNK-106M

Overview

The 4K HDMI optical transceivers are HDMI modules designed for transmitting uncompressed, lossless

HDMI 1.4a signals over multimode optical fiber at 850nm, supporting distances up to 300m and a resolution

of 4Kx2K. The 4K HDMI Optical Transceiver-T converts HDMI signals into a single 10Gb/s serial data stream

for transmission over two optical fibers, while the 4K HDMI Optical Transceiver-R converts this serial data

back into an HDMI signal.

These RoHS-compliant, lead-free transceivers are perfect for applications such as large-screen displays,

conferencing systems, and home entertainment. With strong anti-interference capabilities, they ensure

stable and reliable signal transmission.

Features

Ø HDMI 1.4a and HCCP1.2 Support

Ø Uncompressed transmission,No delay,No losses

Ø DDC CEC HPD Signal Support

Ø Supports up to 300m Transmission Distance at up to 10.3Gbps with OM3 Multimode Fiber (850nm)

Ø Supports All Modes up to 4K*2K@30Hz Resolution

Ø Standard HDMI Connector

Ø Integrated USB Connector for Power

Ø Hot-Pluggable, EMI/RFI Resistant

Ø Miniature form factor for ease of use and installation

Ø 850nm VCSEL and PIN Photodetector

Ø Video over (2) multimode fibers

Ø Typical Power Dissipation 1420 mW (Source), 1220 mW (Sink)

Ø Operating Case Temperature: 0~70°C

Technical Indexes

Type of Extender Fiber Transmitter for HDMI signal over Optical Fiber Cable
Input Signals HDMI
Signal Support HDMI 1.4a HDMI format standard and HDCP compliant
Video Support 1920x1200 / 1080p@60Hz, up to 4K*2K@30Hz
Audio Support Dolby TrueHD, Dolby Digital Plus, DTS, DTS-ES 6.1, DTSHD, DTS-HD-HRA, DTS-HD Master, (PCM-2CH)
Website Specifications Color space 444, 420, 400
Dynamic EDID Plug & Play, no need to learn
Fiber Connector Double LC Receptacle
Transmission Distance Multi Mode, up to 984ft (300M)
Operating Temperature 0°C to + 50°C
Storage Temperature -20°C to + 85°C
Humidity to 90% RH (non-condensing)
Safety Approvals CE, RoHS
Dimension (WxDxH) 3.15 x 0.79 x 0.35 in (80x20x9mm)
Weight 0.1 kg / 0.22 lb
Operation Voltage 5VDC
Power Supply Power Input +5VDC, 0.85A (Universal Type 50/60Hz, 100~240VAC)

Application

Mini 4K HDMI Optical Transceiver with support for HDMI 1.4a and HDCP 1.2

Ordering Information

Item Description
LNK-106M Mini HDMI Optical Transceiver: 1-Ch HDMI 1.4a Video Signal(4K*2K), OM3 Multi-mode Fiber, 300 meters, LC, including 1 transmitter & 1 receiver, used by pairs, USB Power Input
