100M Fiber Optic LAN Card ( Network Interface Card )
100M Fiber Optic LAN Card ( Network Interface Card )
100M Fiber Optic LAN Card ( Network Interface Card )
100M Fiber Optic LAN Card ( Network Interface Card )
100M Fiber Optic LAN Card ( Network Interface Card )
100M Fiber Optic LAN Card ( Network Interface Card )
100M Fiber Optic LAN Card ( Network Interface Card )
100M Fiber Optic LAN Card ( Network Interface Card )
100M Fiber Optic LAN Card ( Network Interface Card )
100M Fiber Optic LAN Card ( Network Interface Card )
100M Fiber Optic LAN Card ( Network Interface Card )
100M Fiber Optic LAN Card ( Network Interface Card )
100M Fiber Optic LAN Card ( Network Interface Card )
100M Fiber Optic LAN Card ( Network Interface Card )
Specifications
Brand Name :
E-link
Model Number :
LNK-LC100-SC
Certification :
ISO9001, CE, ROHS, FCC
Place of Origin :
China
MOQ :
1pcs
Price :
negotiate
Payment Terms :
T/T, Western Union, MoneyGram, PayPal
Supply Ability :
10000/Month
Delivery Time :
3-5 working days
Packaging Details :
Optic LAN Card Standard Carton Packaging
Data Speed :
100Mbits/s (Half duplex), 200Mbits/s (Full duplex)
Host Interface :
PCI 2.2 Specifications
Media :
Single Mode Fiber, Multi Mode Fiber
Voltage :
5- 12V DC
Storage Temperature :
-20℃～65℃
TX/RX data buffer :
Large 2Kb Tx, 2Kb Rx FIFO buffers
Description

100M Fiber Optic LAN Card ( Network Interface Card )

Model:LNK-LC100-SC

Overview

E-link LNK-LC100 Series Single Port Fiber 100M PCI-E NIC (Network Interface Card) have two

kinds of interface: 1X9 Module with SC Connector and SFP Module. It is a Fiber 100M Ethernet

to PCI-E bus adapter that fully complies with all IEEE 802.3u 100Base-FX standards. LNK-LC100-SC

Series Single Port Fiber 100M PCI-E NIC support one SC Fiber port(Duplex Fiber/ Single Fiber Optional),

LNK-LC100-SFP Series Single Port Fiber 100M PCI-E NIC(Network Interface Card) support one SFP

port(Duplex Fiber/ Single Fiber Optional). It can offer 100Mbps Internet access, It provides up to 200Mbps

full-duplex bandwidth capacity to support high-end servers. In addition, with advanced functions like

VLAN filtering packet processing, the adapter provides added performance, flexible configuration and

secure networking for users in a standard-based environment.

Features

► Plug and Play

► IEEE 802.3 Full-Duplex Flow Control

► IEEE 802.3u 100Base-FX

► High bandwidth 100Mbps Network Speed

► Supports Full-Duplex Mode

► Compliant to ACPI 1.0 specification

► IEEE 802.3 Full-Duplex Flow Control

► IEEE 802.1Q VLAN Tagging

► IEEE 802.1p Priority Tagging

► Management statistics gathering

► IP multicast receive and filter support using 64 bit hash table

Technical Indexes

Product Model LNK-LC100 Series: Single Port Fiber 100M PCI-E NIC
Standards IEEE802.3, IEEE 802.3ab, IEEE 802.3x, IEEE802.1q, IEEE802.1p, IEEE802.1z
TX/RX data buffer Large 2Kb Tx, 2Kb Rx FIFO buffers
Port Numbers LNK-LC100-SC Series: SC Connector*1( Duplex Fiber / Single Fiber Optional)
LNK-LC100-SFP Series: SFP*1( Duplex Fiber / Single Fiber Optional)
Media Single Mode Fiber, Multi Mode Fiber
Transmitting Distance Single Fiber SMF, 1310nm/1550nm(1490nm),20/40/60km
Duplex Fiber SMF, 1310nm or 1550nm(1490nm), 20/40/60/km
Duplex Fiber MMF, 850nm, 2Km
Data Speed 100Mbits/s (Half duplex), 200Mbits/s (Full duplex)
Host Interface PCI 2.2 Specifications
Consumption Max. 2W, +5VDC@0.4A
Ambient Temperature Storage Temperature:-20℃～65℃； Storage humidity:5％～90％ RH Non-condensing
Operation temperature:0℃～50℃；Operation humidity:10％～90％ RH Non-condensing

Application

100M Fiber Optic LAN Card ( Network Interface Card )

Ordering Information

Model Description
LNK-LC100-SC 100M Fiber Optic LAN Card, 1310nm, Duplex Fiber, MMF, SC Connector, Transmitting Distance: 2Km
LNK-LC100-SC-20 100M Fiber Optic LAN Card, 1310nm, Duplex Fiber, SMF, SC Connector, Transmitting Distance: 20Km
LNK-LCS100-SC-20 100M Fiber Optic LAN Card, 1310nm TX/1550nm RX, Single Fiber, SMF, SC Connector, Transmitting Distance: 20Km
LNK-LC100-SFP 100M Fiber Optic LAN Card, 1310nm, Duplex Fiber, MMF, SFP*1, Transmitting Distance: 2Km
LNK-LC100-SFP-20 100M Fiber Optic LAN Card, 1310nm, Duplex Fiber, SMF, SFP*1, Transmitting Distance: 20Km
LNK-LCS100-SFP-20 100M Fiber Optic LAN Card, 1310nm TX/1550nm RX, Single Fiber, SMF, SFP*1, Transmitting Distance: 20Km
