Aluminum Case PoE Splitter 5V Power Over Ethernet Splitter 100 Meters
Aluminum Case PoE Splitter 5V Power Over Ethernet Splitter 100 Meters
Aluminum Case PoE Splitter 5V Power Over Ethernet Splitter 100 Meters
Aluminum Case PoE Splitter 5V Power Over Ethernet Splitter 100 Meters
Specifications
Brand Name :
E-link
Model Number :
LNK-INS301-5V
Certification :
ROHS,FCC,CE
Place of Origin :
China
MOQ :
1 pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram, Paypal
Supply Ability :
5000pcs/month
Delivery Time :
5-12 working days
Packaging Details :
PoE Power Splitter Standard Export Package
Keywords :
PoE Power Splitter
Output Voltage :
5VDC Power OUT
Weight :
0.25Kg
Casing :
Aluminum Case
Power Consumption :
25W Max
Mounting Options :
DIN-Rail / Wall-mount
Description

PoE Power Splitter Industrial Gigabit 802.3at 30W Power Over Ethernet 5VDC Output
PoE Power Splitter Advantages
► Splits power and data from PoE Input
► One RJ-45 PoE Port (Data & Power In)
► One RJ-45 Port (Data Out)
► One 5VDC Output (2-pin Terminal Block)
► Support IEEE802.3af/at PoE
► Support 10/100/1000Base-T
► Distance up to 100 meters

Technical Indexes

Ethernet
Standards: IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3ab 1000Base-T Gigabit Ethernet
IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet Plus
Processing Type: Forward
Half-duplex, Full-duplex
Forward Filter Rate: 1,488,000pps (1000Mbps)
Cabling: 1000Base-T: Cat5 or above
Maximum Distance: Cat5 UTP up to 100m
Interface: “PoE (Power + Data)” Input Port: 1 x RJ-45 10/100/1000Base-T
“Data” Out Port: 1 x RJ-45 10/100/1000Base-T
DC Out Plug Connector: 1 removable 2-Pin terminal block
Environmental
Operating Temperature: -40°C to 80°C (-40°F to 176°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Relative Humidity: 5% to 95% non-condensing
MTBF: >200,000hrs
Regulatory Approvals
ISO9001
FCC part 15, Class A
EN55022:2006+A1: 2007 Class A
Surge Protection:
RJ45: 1KV
Power: 500W
ESD: 4KV/8KV

Overview
LNK-INS301-5V series is an Industrial Grade, Gigabit Ethernet, PoE Splitter, designed to deliver data, via RJ-45 Ethernet connector, and electrical power, via screw terminal block, to non-PoE devices. This device saves the high cost of running separate electrical service to edge devices.
Aluminum Case PoE Splitter 5V Power Over Ethernet Splitter 100 Meters
Ordering Information

Model Description
LNK-INS301-5V Industrial IEEE802.3at Gigabit PoE Splitter Output Voltage 5VDC, maximum output of 20W at 5VDC, Support DIN-Rail mounting and Wall mounting installation, -40 to 80°C operating temperature
Mounting Options ► Default DIN-Rail Bracket installed; Wall Mount Bracket is included.
