8 Port Industrial Unmanaged Din Network Switch 10/100BASE-T
8 Port Industrial Unmanaged Din Network Switch 10/100BASE-T
8 Port Industrial Unmanaged Din Network Switch 10/100BASE-T
8 Port Industrial Unmanaged Din Network Switch 10/100BASE-T
Specifications
Brand Name :
E-link
Model Number :
LNK-IMC008
Certification :
RoHS,CE,FCC
Place of Origin :
China
MOQ :
1pcs
Price :
To be negotiated
Payment Terms :
L/C, T/T, Western Union, MoneyGram,Paypal
Supply Ability :
500PCS/Month
Delivery Time :
5-15working days
Packaging Details :
Industrial Ethernet Switch Standard Export Package
Keyword :
Industrial Ethernet Switch
Connector :
8 x RJ45
Power Input Overload :
Power Input Overload
Dimensions :
150 x 110 x 50 mm
Weight :
0.6Kg
Casing :
Aluminum Case
Description

Industrial Ethernet Switch Unmanaged 8-port 10 / 100BASE-T Ethernet Switch

Industrial Ethernet Switch Advantages

► 8 10/100Base-TX ports

► RJ45 Port Supports 10/100Mbps-Full/Half-duplex, Auto-negotiation, Auto MDI/MDIX

► Supports 802.3x Flow control

► IEEE 802.3az Energy Efficient Ethernet (EEE)

► Supports DIN-Rail and Wall-mount installation

► Redundant 12～58VDC Power Inputs

► -40°C to 80°C (-40°F to 176°F) operating temperature

Technical Indexes

Standards: IEEE802.3 10BASE-T
IEEE802.3u 100BASE-TX
IEEE 802.3az Energy Efficient Ethernet (EEE)
IEEE802.3x Flow Control
Forward & Filtering Rate: 14,880pps (10Mbps)
148,800pps (100Mbps)
Cabling 10Base-T: Cat5 or above
100Base-TX: Cat5 or above
Maximum Distance Cat5 UTP up to 100m
Interface
Connector: 8 x RJ45
Environmental
Operating Temperature: -40°C to 80°C (-40°F to 176°F)
MTBF > 200,000 hrs
Electrical and Mechanical
Input Power: 12~58VDC, Redundant Power (6-pin Terminal Block)
Power Consumption: 5W Max.
Protection:
Power Input Overload: Automatic Resettable
Reverse Polarity: Present
LED Indicators:
Power: Power1, Power2 Status
Ethernet (Per Port): Link/Activity
Dimensions (WxDxH): 150 x 110 x 50 mm
Weight: 0.6Kg
Casing: Aluminum Case
Mounting Options: DIN-Rail / Wall-mount
Regulatory Approvals
ISO9001
EN55022:2010+AC: 2011, Class A
EN 61000-3-2: 2006+A1: 2009+A2: 2009

Overview

LNK-IMC008 is an 8 ports 10/100Base-TX Hardened Ethernet Switch. This unmanaged industrial Ethernet switch is designed to match the critical industrial standards. With reliable and simple operation against vibration and shock, and wide operation temperature range, it could match a variety of harsh environment.

The switch complies with CE and FCC standards, and passed the 100% burning test to ensure that it will fulfill the needs of industrial applications. It is a good choice for an economical solution for industrial Ethernet connections.

8 Port Industrial Unmanaged Din Network Switch 10/100BASE-T

Ordering Information

Model Description
LNK-IMC008 Industrial 8-port 10/100BASE-T Ethernet Switch
Mounting Options ► Default DIN-Rail Bracket installed; Wall Mount Bracket is included.
Power Options ►24W/1A 24VDC DIN-Rail Power Supply. Open Wire for Terminal Block.
► Power Supply is to be purchased separately.
