L2+ 24-Port 10 100 1000T 802.3at PoE + 4-Port Gigabit TP SFP Combo Managed Switch
L2+ 24-Port 10 100 1000T 802.3at PoE + 4-Port Gigabit TP SFP Combo Managed Switch
L2+ 24-Port 10 100 1000T 802.3at PoE + 4-Port Gigabit TP SFP Combo Managed Switch
L2+ 24-Port 10 100 1000T 802.3at PoE + 4-Port Gigabit TP SFP Combo Managed Switch
L2+ 24-Port 10 100 1000T 802.3at PoE + 4-Port Gigabit TP SFP Combo Managed Switch
L2+ 24-Port 10 100 1000T 802.3at PoE + 4-Port Gigabit TP SFP Combo Managed Switch
L2+ 24-Port 10 100 1000T 802.3at PoE + 4-Port Gigabit TP SFP Combo Managed Switch
L2+ 24-Port 10 100 1000T 802.3at PoE + 4-Port Gigabit TP SFP Combo Managed Switch
L2+ 24-Port 10 100 1000T 802.3at PoE + 4-Port Gigabit TP SFP Combo Managed Switch
L2+ 24-Port 10 100 1000T 802.3at PoE + 4-Port Gigabit TP SFP Combo Managed Switch
Specifications
Brand Name :
e-link
Model Number :
TS-M324GP-4G4SFP
Certification :
ROHS,FCC,CE
Place of Origin :
China
MOQ :
1pcs
Price :
negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal
Supply Ability :
1000 pcs/month
Delivery Time :
5-12 working days
Packaging Details :
PoE Ethernet Switch Standard Export Package
Keywords :
Commercial PoE Switch
Connector :
24 x RJ45
Dimensions :
440mm x 290mm x 45mm (L x W x H)
Installation mode :
Rack Mounting
Weight :
3600g
Power budget :
Max. PoE output power budget 30W
Description

L2+ 24-Port 10/100/1000T 802.3at PoE + 4-Port Gigabit TP/SFP Combo Managed Switch
Commercial PoE Switch Advantages

► 24-Port 10/100/1000BASE-T RJ45 copper with IEEE 802.3at/af Power over Ethernet Injector function

► 4-Port 10/100/1000Mbps TP and SFP shared combo interfaces, supporting 100/1000Mbps dual mode

► RJ45 console interface for basic management and setup

► Web smart management for easy application.

► Bandwidth management based on port input and output

► SNMP V1/V2/V3 management

► Support loop protection, automatic recovery

► Plug & play, no configuration required

Tchenical Indexes

Physical Port
RJ45 port and speed 24x10/100/1000Base-TX 802.3at PoE
Fiber port and speed 4xGigabit TP/SFP Combo Managed Switch
Packet buffer 4Mbits
MAC address table 8K
Transmission mode Store and Forward (full/half duplex mode)
Exchange property Delay time: < 7μs
Backplane bandwidth: 56Gbps
PoE
PoE Standard 24x IEEE 802.3af /IEEE 802.3at PoE
Power budget Max. PoE output power budget 30W
Power Information
Power

Built-in power AC 100~240V 50/60Hz

MAX Current 5.2A

MAX Power 400W
Physical Property
Protection grade IP30
Dimensions 440mm x 290mm x 45mm (L x W x H)
Installation mode Rack Mounting
Weight 3600g
Working Environment
Operating Temperature -20℃~55℃
Storage Temperature -40℃~75℃
Warranty
MTBF 200,000 hours
Defects Liability Period 1 year warranty, lifetime technical support
Certification Standard
EMI

FCC Part15 Subpart B Class A,

EN 55022 Class A

Overview

TS-M324GP-4G4SFP Layer 2 Managed Gigabit Switch provides 24 10/100/1000BASE-T ports featuring 36-watt 802.3at PoE+, and 4 extra Gigabit TP/SFP combo interfaces. Each of the eight Gigabit ports provides 36 watts of power, with a total power budget of up to 400 watts for the different types of PoE applications being employed. It provides a quick, safe and cost-effective Power over Ethernet network solution to IP security surveillance for small businesses and enterprises.

Due to its dependable design and user-friendliness, this product emerges as an optimal selection for bridging networks composed of devices like IP cameras and wireless access points across disparate locations.

L2+ 24-Port 10 100 1000T 802.3at PoE + 4-Port Gigabit TP SFP Combo Managed Switch

L2+ 24-Port 10 100 1000T 802.3at PoE + 4-Port Gigabit TP SFP Combo Managed Switch

Ordering Information

Model Description
TS-M324GP-4G4SFP L2+ 24-Port 10/100/1000T 802.3at PoE + 4-Port Gigabit TP/SFP Combo Managed Switch, total power budget of up to 400 watts
Mounting Options ► Desktop or Rack Mounting Installation
SFP Options ► SFP option. Please select your SFP on our SFP Options Page
► SFP module is to be purchased separately.
