Specifications
Brand Name :
HL
Model Number :
HL-ME003
Certification :
ISO9001,ROHS
Place of Origin :
Chengdu
MOQ :
100PCS
Price :
Negotation($20-$30)
Payment Terms :
L/C, T/T
Supply Ability :
1000000PCS per Month
Delivery Time :
10 Work days
Usage: :
Security & Protection
Theory :
Infrared Sensor
Output :
Digital Sensor
Working Voltage Range :
DC4.5 to 20V
Max. detection distance: :
about 7m
Color :
Black
Description

Adjustable IR Pyroelectric infrared PIR motion sensor detector module with black lens PIR motion

Features:

1 Infrared sensor with control circuit board;
2 The sensitivity and holding time can be adjusted;
3 Small and light, it is easy to use;
4 Detecting distance is up to 7m;
5 Suitable for the field of security, toy, automation control etc.;

Specifications:

1 Working voltage: DC 4.5V--20V;
2 Quiescent Current: Less than 50uA;
3Voltage output: High/Low level signal:3.3V TTL output;
4 Detection distance: 3--7M(can be adjuted);
5 Detection angle: <100 degree;

6 Delay time: 5-200S (can be adjuted, default 5s +-3%);
7 Blockade time: 2.5S (default);
8 Trigger method: L: unrepeatable trigger H: repeatable trigger(default);
9 Photosensitive setting: Use CDS (Defaut: included, not welded);
10 Working temperature: -15- +70degree;

11 Product weight: 6g;
12 PCB size: 3.2 * 2.4 * 2.4cm;

IR Pyroelectric Infrared PIR Long Range Ultrasonic Sensor

IR Pyroelectric Infrared PIR Long Range Ultrasonic Sensor

IR Pyroelectric Infrared PIR Long Range Ultrasonic Sensor

IR Pyroelectric Infrared PIR Long Range Ultrasonic SensorIR Pyroelectric Infrared PIR Long Range Ultrasonic SensorIR Pyroelectric Infrared PIR Long Range Ultrasonic Sensor
