70W 230V AC Input Only Panel Mount Power Supply Metal Case 100 % Full Load
70W 230V AC Input Only Panel Mount Power Supply Metal Case 100 % Full Load
70W 230V AC Input Only Panel Mount Power Supply Metal Case 100 % Full Load
70W 230V AC Input Only Panel Mount Power Supply Metal Case 100 % Full Load
70W 230V AC Input Only Panel Mount Power Supply Metal Case 100 % Full Load
70W 230V AC Input Only Panel Mount Power Supply Metal Case 100 % Full Load
Specifications
Brand Name :
HAOLI
Certification :
CE，ISO9001，ROHS
Place of Origin :
ChengDu
Payment Terms :
L/C, D/A, D/P, T/T
Delivery Time :
10 work days
MOQ :
1000
Price :
Negotiation
Input frequency :
50HZ~ 60Hz
Hold up time :
≥20ms @ 230VAC full load
Overload protection :
150% of the rated output power
Operating temperature :
-20℃~40℃
Safety standard :
EN60950, GB4943-2001
Weight :
0.45kg/pcs
Description

70W Single Output (230V AC input only) Industrial Power Supply

Product features


230VAC input only

Power on indication

Metal case
Protections: Overload / Short circuit

Battery reverse charge protection

100% full load burn-in test

1 year warranty

Specifications
Input voltage 195VAC~253VAC
Input frequency 50HZ~ 60Hz
Inrush current 40A @ 220VAC full load cold start
Hold up time ≥20ms @ 230VAC full load
Overload protection 150% of the rated output power
Operating temperature -20℃~40℃
Safety standard EN60950, GB4943-2001
EMC standard EN55022 Class B, EN55024
Withstand voltage I/P-O/P: 3kVAC, 1min
I/P-FG: 1 .5kVAC, 1min
O/P-FG: 0.5kVAC, 1min
Weight 0.45kg/pcs
70W 230V AC Input Only Panel Mount Power Supply Metal Case 100 % Full Load70W 230V AC Input Only Panel Mount Power Supply Metal Case 100 % Full Load70W 230V AC Input Only Panel Mount Power Supply Metal Case 100 % Full Load
Our Advantages

OEM&ODM SERVICE
This company is engaged in the design,manufacture and sale of switching power series
LONG-TIME BURN-IN TEST
Each of the switch power is extremely safe and stable after 5 times testing
With high reliability,105℃long life capacitor,can withstand 300VAC,input voltage 5 seconds without damage
70W 230V AC Input Only Panel Mount Power Supply Metal Case 100 % Full Load
70W 230V AC Input Only Panel Mount Power Supply Metal Case 100 % Full Load
70W 230V AC Input Only Panel Mount Power Supply Metal Case 100 % Full Load
70W 230V AC Input Only Panel Mount Power Supply Metal Case 100 % Full Load
P/N Output Tol. R&N Effi. Load Regulation
ESP-70-13.8 13.8V,5A ±3% 120mV 76% ±2%
ESP-70-27.6 27.6V,2.5A ±3% 240mV 80% ±2%

FAQ

Q1: How many year warranty of your Led driver?
A: One years
Q2: Do you have switch power factory?
A: Yes.We are OEM&ODM manufacturer in Chengdu
Q3 : Do you offer sample of power?
A: Yes.We offer free sample ,but you need pay the shippment.
Q4: Is your power with copper transform or something?
A: We can do with complete copper transform and copper cladding aluminum.
Q5: Do you have any certification?
A: Yes.We have CE,ISO9001,ROHS,if you need other certification with large order,we can apply for it
