High Reliability Single Mode Power Supply , 20ms Mounted 25w Power Supply
High Reliability Single Mode Power Supply , 20ms Mounted 25w Power Supply
High Reliability Single Mode Power Supply , 20ms Mounted 25w Power Supply
High Reliability Single Mode Power Supply , 20ms Mounted 25w Power Supply
Specifications
Brand Name :
HAOLI
Model Number :
EPR
Certification :
CE，ISO9001，ROHS
Place of Origin :
Chengdu
MOQ :
1000
Payment Terms :
L/C, D/A, D/P, T/T
Delivery Time :
10 work days
Input Voltage :
88VAC-264VAC,124VDC-370VDC
Input Frequency :
47HZ-63HZ
Incursh Current :
30A@230VAC full load cold start
Hold up time :
≥2ms@230VAC full load
Overload protection :
110%~ 180% auto-recovery
Weight :
0.17kg/pcs
Price :
Negotiation
Description

25W Single Output Industrial Power Supply EPR-25 Mounted Power Supply

Product features


Universal AC input / full range

Power on indication
Protections: Overload / Short circuit
High reliability: 105℃ capacitor, withstand 300VAC surge input for 5s

100% full load burn-in test

2 years warranty

Specifications

Input voltage: 88VAC~264VAC, 124VDC~370VDC
Input frequency: 47Hz~63Hz
Inrush current: 30A @ 230VAC full load cold start
Hold up time: ≥20ms @ 230VAC full load
Overload protection: 110%~ 180% auto-recovery
Operating temperature: -20℃~70℃ (refer to output derating curve)
Safety standard: UL60950-1
EMC standard: EN55022 Class B, EN55024
Withstand voltage: I/P-O/P: 1.5kVAC, 1min
I/P-FG: 1.5kVAC, 1min
O/P-FG: 0.5kVAC, 1min
Weight 0.17kg/pcs
High Reliability Single Mode Power Supply , 20ms Mounted 25w Power Supply
High Reliability Single Mode Power Supply , 20ms Mounted 25w Power Supply
High Reliability Single Mode Power Supply , 20ms Mounted 25w Power Supply
Our Advantages

OEM&ODM SERVICE
This company is engaged in the design,manufacture and sale of switching power series
LONG-TIME BURN-IN TEST
Each of the switch power is extremely safe and stable after 5 times testing
With high reliability,105℃long life capacitor,can withstand 300VAC,input voltage 5 seconds without damage
High Reliability Single Mode Power Supply , 20ms Mounted 25w Power Supply
High Reliability Single Mode Power Supply , 20ms Mounted 25w Power Supply
High Reliability Single Mode Power Supply , 20ms Mounted 25w Power Supply
High Reliability Single Mode Power Supply , 20ms Mounted 25w Power Supply
High Reliability Single Mode Power Supply , 20ms Mounted 25w Power Supply
P/N Output Tol. R&N Effi. Load Regulation DC adjustment range
EPR-25-5 5V,5A ±3% 80mV 76% ±2% 4.75V~5.25V
EPR-25-12 12V,2.1A ±3% 120mV 79% ±2% 10.8V~13.2V
EPR-25-24 24V,1.1A ±3% 120mV 81% ±2% 21.6V~26.4V
EPR-25-48 48V,0.57A ±3% 200mV 83% ±2% 43.2V~52.8V
