4-20mA Smart Pressure Transmitter Sanitary Flush φ50.4mm Smart Pressure Sensor
4-20mA Smart Pressure Transmitter Sanitary Flush φ50.4mm Smart Pressure Sensor
4-20mA Smart Pressure Transmitter Sanitary Flush φ50.4mm Smart Pressure Sensor
4-20mA Smart Pressure Transmitter Sanitary Flush φ50.4mm Smart Pressure Sensor
Specifications
Certification :
CE,RoHs,ISO9001
Place of Origin :
Baoji,China
Brand Name :
HT SENSOR
MOQ :
1
Price :
Negotiable
Packaging Details :
Standard Export Package
Delivery Time :
5-8 work days
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
5000PCS/Month
Model Number :
BT93420-IQT
Model NO. :
BP93420-IQT Smart Pressure Transmitter
Accuracy Grade :
0.5%
Pressure range :
-100kpa...0kpa ~35kpa...3.5MPa
Protection Rating :
IP65
Weight :
~0.3kg
Frequency Response :
2.4kHz
Housing Material :
316L
Pressure Type :
Gauge Pressure, Absolute Pressure, Sealed Pressure
Measuring Medium :
Liquid
Customization :
Available | Customized Request
Description

4-20mA Sanitary Flush Φ50.4mm Smart Pressure Transmitter Pressure Sensor

BP93420-IQT Sanitary Pressure Transmitter


Introduction of Sanitary Pressure Transmitter:
BP93420-IQT pressure transmitter utilizes the HT series silicon pressure-resistance isolation oil-filled core as the signal measuring element. It features a full metal flush diaphragm and direct welding with the process connection, ensuring precise connections between the process connection and the measuring diaphragm. The entire product has undergone rigorous testing ensuring stable and reliable performance and effectively preventing the problem of pressure hole blockage caused by crystallizing media.
4-20mA Smart Pressure Transmitter Sanitary Flush φ50.4mm Smart Pressure Sensor
4-20mA Smart Pressure Transmitter Sanitary Flush φ50.4mm Smart Pressure Sensor
4-20mA Smart Pressure Transmitter Sanitary Flush φ50.4mm Smart Pressure Sensor




Product Features of Sanitary Pressure Transmitter:
1. Various pressure interface options
2. Diverse output signal options
3. High accuracy,multiple sterile process connections


Applications of Sanitary Pressure Transmitter:
1. Suitable for measuring non-corrosive gases and liquids with 316L
2. Medical, biopharmaceutical, and food hygiene industries for sterile processing
3. Used in the paper and chemical industries, as well as for sewage level and beverage can pressure measurements Suitable for hydraulic and pneumatic control systems

Performance Parameters
Measurement Range -100kPa…0kPa ~ 35kPa…3.5MPa
Pressure Type Gauge Pressure, Absolute Pressure, Sealed Pressure
Overload ≤ 1.5 times of the rated range
Accuracy @ 25ºC ±0.25% (Typical) ±0.5% (Maximum)
Repeatability ≤0.1%FS
Hysteresis ≤0.1%FS
Long-Term Stability ±0.1%F.S/Year(Typical) ±0.2%F.S/Year(Maximum)
Zero Point Temperature Drift ±0.02%F.S/ºC(≤100KPa) ±0.01%F.S/ºC(>100KPa)
Full Scale Temperature Drift ±0.02%F.S/ºC(≤100KPa) ±0.01%F.S/ºC(>100KPa)
Frequency Response 2.4Khz
Compensation Temperature 0-70ºC(≤10mpa,customizable)
Operating Temperature -20ºC~80ºC
Storage Temperature -40ºC~120ºC
Vibration 10g,55Hz ~ 2kHz
Housing Material 304,316L
Diaphragm Material 316L
Insulation Resistance 100MΩ 100VDC
Explosion-proof Rating Ex db IIC T6 Gb
Protection Rating IP65
O-Ring Seal Fluoro rubber
Weight ~0.3kg
Output Signal Supply Voltage Output Type
4~20mA 12~30VDC 2/3/4 wire
0~10/20mA
3 wire
0/1~5V
0/1~10V
0.5~4.5V 5VDC
RS485 Communication Protocol 3.6~30V / Battery 4 wire


4-20mA Smart Pressure Transmitter Sanitary Flush φ50.4mm Smart Pressure Sensor

4-20mA Smart Pressure Transmitter Sanitary Flush φ50.4mm Smart Pressure Sensor


4-20mA Smart Pressure Transmitter Sanitary Flush φ50.4mm Smart Pressure Sensor




4-20mA Smart Pressure Transmitter Sanitary Flush φ50.4mm Smart Pressure Sensor

Ordering tips
1. Ensure that the medium to be measured is compatible with the contact parts of the product.
2. To ensure reliable operation of the product, it is recommended that users install lightning protection devices on-site and ensure that the product and power supply are reliably grounded.
3. The Fluoro rubber O-ring has a rated working temperature range of -20ºC to 250ºC. If the product's operating temperature is below -20ºC, an EPDM O-ring seal should be chosen instead.
4. For special requirements such as strong vibration, instantaneous impact force, strong electromagnetic or radio frequency interference, please inform our company and specify them in the order.
Order Guide
BP93420XX Pressure Transmitter
Code Outline Construction
IB General Pressure Transmitter IX Display Pressure Transmitter
IE Shock-resistant Aviation Pressure Transmitter IIC/III Industrial General/ Display Pressure Transmitter
IF Moisture-proof Pressure Transmitter IIE/IIIE General/Display Pressure Transmitter
IN Air Conditioning Dedicated Pressure Transmitter
IC High-temperature Pressure Transmitter
IQ1/IQ2 Large Diaphragm /High-temperature Pressure Transmitter
Measurement Range -100kPa…0kPa ~ 35kPa…3.5MPa
(0-X)Kpa or MPa X: Indicates the Actual Measuring Range
Code Power Supply
D1 24VDC
D2 5VDC
D3 Other
Code Output Signal
S1 4~20mADC S5 0~20mADC
S2 1~5VDC S6 0~10VDC
S3 0~5VDC S7 0.5~4.5VDC
S4 0~10mADC
Code Pressure Connection
J1 M20×1.5
J2 G1/2
J3 G1/4
J4 7/16-20UNF
J5 Other
Code Electrical Connection
B1 Hirschmann
B2 PG7 Plug
B3 Sealed Cable Output
B4 2088 Industrial Casing
B5 2088 Industrial Casing with Display
B6 Other
Code Pressure Type
G Gauge Pressure
A Absolute Pressure
S Sealed Reference Pressure
