BPZK04 Electronic Pressure Switch The Perfect Combination of Measurement and Control
BPZK04 Electronic Pressure Switch The Perfect Combination of Measurement and Control
BPZK04 Electronic Pressure Switch The Perfect Combination of Measurement and Control
BPZK04 Electronic Pressure Switch The Perfect Combination of Measurement and Control
Specifications
Brand Name :
HT SENSOR
Model Number :
BPZK04
Certification :
ISO9001
Place of Origin :
Baoji，China
MOQ :
1
Price :
Negotiable
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
5000PCS/Month
Delivery Time :
5-8 work days
Packaging Details :
Standard Export Package
Model NO. :
BPZK04
Power supply :
24VDC
Output :
4-20mA 3wire
Protection :
IP65
Diaphragm :
SS316L
Transport Package :
Carton
Specification :
0-10kpa~40mpa
Origin :
Baoji，China
Number of Switch :
2 Control Switch
Long-Term Stability :
±0.3%F.S/year
Description

BPZK04 Electronic Pressure Switch The Perfect Combination of Measurement and Control

BPZK04 Electronic Pressure Switch

Introduction of electronic pressure switch :

The BPZK04 electronic pressure switch is a fully digital control product that integrates pressure measurement, control display, transmission, and output. When the pressure of non-corrosive gas or liquid reaches the set value of the switch, it immediately activates to turn on or off the device. Its compact size and lightweight design make it suitable for installation in environments with tight space requirements such as aircraft, ships, and vehicles. With adjustable operating pressure and convenient, accurate control capabilities, it can be directly installed on field pipelines.

Product Features of electronic pressure switch:

  • Stainless steel structural design with versatile pressure interface options.
  • with high-brightness LED pressure display.
  • Powered 24VDC or 24VAC.
  • Can provide up to two control relay outputs, with the ability to set arbitrary relay values and states for precise and reliable control.
  • High accuracy.


Applications of electronic pressure switch:


Measurement and control of pressure/differential pressure of fluid media in industries such as hydropower, metallurgy, and chemical engineering, for automatic control applications.


Performance Parameters of Electronic Pressure Switch
Measurement Range -100kPa…0kPa ~ 10kPa…100MPa
0-10KPa~2MPa(Differential Pressure)
Pressure Type Gauge Pressure, Absolute Pressure, Sealed Pressure,Differential Pressure
Overload ≤ 1.5 times of the rated range
Accuracy @ 25ºC ±0.25% (Typical) ±0.5% (Maximum)
Long-Term Stability ±0.3%F.S/year
Zero Point Temperature Drift ±0.02%F.S/ºC(≤100KPa) ±0.01%F.S/ºC(>100KPa)
Full Scale Temperature Drift ±0.02%F.S/ºC(≤100KPa) ±0.01%F.S/ºC(>100KPa)
Compensation Temperature 0-50ºC(0-10KPa, 0-20KPa) ,0-70ºC ,-10-70ºC
Operating Temperature -20ºC~80ºC
Storage Temperature -40ºC~120ºC
Diaphragm Material 316L
Insulation Resistance 100MΩ 100VDC
Relay Control 1-2 channels of control or electronic switch quantity control
Contact Life Exceeds 100,000 cycles
Display Range -1999~9999
Installation Method vertical axis installation
Explosion-proof Rating Intrinsically Safe
Protection Rating IP65
Weight ~0.4kg

BPZK04 Electronic Pressure Switch The Perfect Combination of Measurement and Control

BPZK04 Electronic Pressure Switch The Perfect Combination of Measurement and Control
Ordering tips of Electronic Pressure Switch

1, when selecting the product, please ensure that the product is suitable for the parts in contact with the measured medium.

2, please specify the power supply, accuracy level, control point when ordering.

3, stainless steel diaphragm pressure controller measuring range is 0~10KPa ~ 60MPa.

4, for users who choose differential pressure measurement, attention should be paid to ensure that there is an appropriate relationship between the differential pressure range and the allowable overpressure and maximum pressure of high and low pressure chambers to meet the field application requirements. In order to ensure the safe and reliable operation of this product, it is recommended to install a three-valve manifold between the measuring point and the transmitter.

5. In order to ensure the reliable operation of the equipment, it is recommended to install lightning protection devices on site and ensure the reliable grounding of the product and power supply. If there are special requirements such as strong vibration, instantaneous impact force, strong electromagnetic or RF interference, please inform our company when ordering.

BPZK04 Electronic Pressure Switch The Perfect Combination of Measurement and Control BPZK04 Electronic Pressure Switch The Perfect Combination of Measurement and ControlBPZK04 Electronic Pressure Switch The Perfect Combination of Measurement and ControlBPZK04 Electronic Pressure Switch The Perfect Combination of Measurement and ControlBPZK04 Electronic Pressure Switch The Perfect Combination of Measurement and Control
