Low Noise Industrial Screw Compressor With Vector Frequency Converter

converter of Industrial Screw Compressor

• Standard equipment with radio-frequency reactor which effectively reduces magnetic field interference outside high-frequency machine generated by frequency converter;
• Reliably reduces peak current when it is started, realizes stable starting;
• Saves cost of electrical power units;equipped with standard dust screen, circuit board is processed with surface coating, so antifouling, anti-dust and damp-proof effects are realized;
• equipped with standard dust screen, circuit board is processed with surface coating, so antifouling, anti-dust and damp-proof effects are realized;
• Special heat dissipation design prevents tripping under summer high temperature;
• Standard protocol of CAN with wire road standard of hardware and strong noise resistance;
• Rapidly track change of pressure, control pressure fluctuation within ±0.01Mpa, optimal power is used to accurately provide necessary air amount;
• Advanced integrated draught fan, and motor uses double-vector variable-frequency control technology.

Variable-frequency control range is broader with more energy conservation

It has advantages of low rotating speed high output torque, variable-freciuency control mode is broader than ordinary inductive variable-frequency motor, especially its 30%-80% air consumption in low-loaa working area saves by 15%-38% when compared with that of power-frequency compressor, and by 10% when compared with ordinary variable-frequency compressor. The lower load ratio, the more obvious the enerqv-savinq effect.

Leading constant pressure control

AVF permanent magnet variable frequency screw compressors can sustain the air supply at the pressure of 0.1 bar in any loading conditions. In case of larger demands for air supply, the compressor can increase its rotation speed without changing the pressure to guarantee the air volume. In case of lower demands for air supply, the compressor can reduce its rotation speed without changing the pressure to meet such demands. In case of no demands for air supply, the compressor will switch to sleep mode to save energy. When actual pressure achieves the wakening standard, the compressor will immediately start up with rapid response of frequency converters even in sleep mode.

Reduce energy costs

• When the energy accounts for above 70% of the life cycle cost (LCC) of compressor, the energy consumption optimization becomes essential. In fact, the power consumption for the production of compressed air accounts for over 40% of the total power consumption of the plant, so the energy consumption optimization can even determine its success. Using the permanent-magnetism frequency-conversion technology of Dresdnerlan, we can provide partners for your cost saving. WZS series of products can truly reflect the demand for compressed air, making substantial energy saving become a reality
• Traditional compressors are operated between two set pressure points using the control methods of "full load and no load". The compressor turns into no load mode when the pressure reaches the maximum. When the air demand is medium or low, the no-load power will be consumed excessively, which will result in large amount of waste.
• Because no unnecessary power consumption will be generated, the energy cost reduced by the permanent-magnetism frequency-conversion can be up to 35% or more. The life cycle cost (LCC) of the compressor can be reduced by an average of 22%. In a word, compared with the compressor with invariable rotate speed, Wan Beardsley compressor can recover the extra cost within 1 or 2 years.

Industrial Screw Compressor Parameters

FAQ:
1. Before quoting, what should users offer?
1). Discharge pressure (Bar, Mpa or Psi)
2). Air discharge/Air flow/Air capacity (m3/min or CFM
3). Power supply (220/380V, 50/60Hz, 3Phase)
2. If I don't know the pressure and air flow, what should I do?
1). Take the picture of nameplate, we will advise the suitable air compressor to you.
2).T ell us what industry you are, we can advise the suitable one (so as to air tank / air dryer / air filters).
