5kg Solvey Galden Heat Transfer Fluid HT80 Perfluoropolyether Fluorinated Fluids PFPE
5kg Solvey Galden Heat Transfer Fluid HT80 Perfluoropolyether Fluorinated Fluids PFPE
5kg Solvey Galden Heat Transfer Fluid HT80 Perfluoropolyether Fluorinated Fluids PFPE
5kg Solvey Galden Heat Transfer Fluid HT80 Perfluoropolyether Fluorinated Fluids PFPE
Specifications
Brand Name :
Solvey Galden
Model Number :
HT80
Certification :
CE
Place of Origin :
Italy
MOQ :
1
Price :
Contact us
Payment Terms :
T/T / Paypal
Supply Ability :
50
Delivery Time :
3-5 work days
Packaging Details :
New Original Box
Model :
HT80
Type :
Heat Transfer Fluid
Boiling point :
80℃
Pour point :
<-110 ℃
Brand :
Solvey Galden
Net weight :
5KG
Description

5kg Solvey Galden Heat Transfer Fluid HT80 Perfluoropolyether Fluorinated Fluids PFPE

HT80 PFPE Heat Transfer Fluid 5 kg / 1 Gal Bottle

Solvey Galden Perfluoropolyether Fluorinated Fluids PFPE is a line of high-performance, inert, fluorinated fluids used as heat transfer and for various high-tech applications in the Electrical & Electronics and Semiconductors markets.

Solvey Galden HT80 PFPE heat transfer fluid is a line of dielectric fluids with boiling points ranging from 55° C to 270° C. The excellent dielectric properties of these perfluorinated polyethers (PFPE) and their high chemical stability combined with the capacity to operate at very low as well as elevated temperatures, make them the best heat transfer fluids for the aggressive conditions found in semiconductor, electronic, and solar industries.

Key Features

1.High thermal stability
2.Wide operating temperature range
3.Good dielectric properties
4.Excellent chemical inertness
5.Good compatibility with metals, plastics and elastomers
6.No flash or fire point, no auto-ignition point
7.Safety (FM approved 6930 standard)

High Boiler Grades

Solvey Galden High Boilers (HBs) is the family of heat transfer synthetic fluids engineered for high temperature applications which feature:

1.The highest boiling points among fluorinated heat transfer fluids
2.Very low vapor pressure and evaporation tendency
3.Outstanding non-flammability
4.Excellent chemical inertness
5.Safety (FM approved 6930 standard)

Solvey Galden HBs are the best candidates for use at temperatures above 150° C to 270° C without pressure build-up and absolutely no fire hazard.

Among the advantages of a sound safety profile for high temperature applications is a positive impact on the Cost of Ownership.

Typical applications for Solvey Galden HBs

1.Heat transfer management in the photovoltaic cell manufacturing process
2.Heat vector in the solar thermal industry
3.Heating fluid
4.Metallurgy
5.Energy sector

Perfluoropolyether Fluorinated Fluids

Property HT55 HT70 HT90 HT110 HT135 HT170 HT200 HT230 HT270
Avg Molecular Weight 340 410 460 580 610 760 870 1020 1550
Normal Boiling Point(℃) 55 70 90 110 135 170 200 230 270
Pour Point (℃) <-110 <-110 <-110 <-110 <-100 <-97 <-85 <-77 <-66
Open Cup Flashpoint none none none none none none none none none
Flannability Range (vol%) none none none none none none none none none
Surface Tension (dynes/cm) 10 14 16 16 17 18 19 19 20
Vapor Press (mm/Hg)@25℃ 225 141 48 17 8 <1 <1 <1 <0.01
Density (g/ml) 1.65 1.68 1.69 1.71 1.72 1.77 1.79 1.82 1.85
Viscosity (cSt)@25℃ 0.45 0.5 0.75 0.77 1 1.8 2.4 4.4 14
Heat of Vaporization (cal/g) @bp 22 17 17 17 16 16 15 15 15
Atmospheric Lifetime (yrs) >800 >800 >800 >800 >800 >800 >800 >800 >800
PFPE heat transfer fluid Operating temperature range
