GE FANUC IC697CMM742 ， Ethernet Interface Designed ， Series 90-70 Type 2
GE FANUC IC697CMM742 ， Ethernet Interface Designed ， Series 90-70 Type 2
GE FANUC IC697CMM742 ， Ethernet Interface Designed ， Series 90-70 Type 2
GE FANUC IC697CMM742 ， Ethernet Interface Designed ， Series 90-70 Type 2
GE FANUC IC697CMM742 ， Ethernet Interface Designed ， Series 90-70 Type 2
GE FANUC IC697CMM742 ， Ethernet Interface Designed ， Series 90-70 Type 2
Specifications
Brand Name :
GE
Model Number :
IC697CHS791
Place of Origin :
USA
MOQ :
1
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
100
Delivery Time :
5-8 work days
Packaging Details :
New in original box
Brand :
GE Fanuc
Model :
IC697CHS791
Series :
Series 90-70
Product Type :
TCP/IP Ethernet (Type 2) Interface Module
Voltage Rating :
12 Volts DC
Current Rating :
0.5 Amps
Network Ports :
10Base-T RJ-45 Port, 10Base2 BNC Port, and AUI
Station Manager Port :
RJ-11 Serial RS-232 Local Station Manager Port
Software Load Port :
15-Pin D-Type Serial Software Load Port
warranty :
1 year
Description

GE FANUC IC697CMM742 , Ethernet Interface Designed , Series 90-70 Type 2

Product Description


The IC697CMM742 module is an Ethernet Interface designed by GE for series 90-70 Type 2. The IC697CMM742 module is equipped with three network ports that establish connection between the IC697 PLC and Ethernet LAN. The Ethernet interface module’s network port is standard and designed with 15 pins that offer a choice of 10Base5, 10Base2, 10BaseT, 10BaseF, or 10Broad36 medium with a user-supplied 802.3-compatible transceiver.

The IC697CMM742 Ethernet interface (type 2) also includes preloaded firmware for simple installation; additionally, firmware is easy to upgrade and maintained indefinitely. This interface provides data exchange via configuration/logic-based Ethernet global data, TCP/IP communication via SRTP, full PLC programming/configuration, and comprehensive station management/diagnostic tools.

The IC697CMM742 Ethernet interface is equipped with four LEDs: MODULE OK, LAN ONLINE, SERIAL ACTIVE, and STATUS OK. If diagnostics are successful, the MODULE OK LED will emit ON. If diagnostics fail, the LED will remain OFF. Blinking during diagnostics is normal and/or indicates special operation conditions. The LAN ONLINE LED will emit ON when connected to the network and ready. It will emit OFF if there is a disruption or malfunction. Blinking is normal to indicate transferring data. SERIAL ACTIVE will show OFF during inactivity and will blink during data transfer. STATUS OK is ON indicates normal operation. OFF indicates an event that needs the user’s attention, and again, blinking is normal.

The IC697CMM742 is also equipped with a restart button that has four purposes: LED test, restart, restart and enter software load state and restart and enter maintenance state. Please see the IC697CMM742 manual for additional information.

Technical Information

Specifications

GeneralSpecifications:

+5 VDC, +12 VDC (from PLC power supply)

2.0 Amps (+5 VDC), typical

0.5 Amps (+12 VDC), maximum when powering an external AUItransceiver

0o C to +55oC (32oF to 131oF), ambient

MODULE OK LANONLINE SERIALACTIVE STATUS

– Station Manager (RS-232) Port: 6-pin female RJ-11

– Software Load (RS-485) Port: 15-pin female D-connector

– 10BaseT Port: 8-pin female RJ-45

– AUI Port: 15-pin female D-connectorwithslide-lock

– 10Base2 port: female BNC connector

5 x 20mm, 250V, 1.0A, slow acting
ModuleOperatingVoltage
ModuleCurrentDrain
ModuleOperatingTemperature
LEDIndicators

Connectors

Fuse, Replaceable
InterfaceSpecifications:

IEEE 802.2 Logical Link Control Class I

IEEE 802.3 CSMA / CDMediumAccess Control 10Mbps

Station Mgr Port: RS-232 DTE 300 - 19200 bps Software Load Port: RS-485 DTE 300 - 19200 bps

10BaseTPort: Ethernet, IEEE 802.3 CSMA / CD 10Base2 Port: Ethernet, IEEE 802.3 CSMA / CD AUI Port: Ethernet, IEEE 802.3 CSMA / CD

(transceiver SQE must be enabled)
LAN
Serial Ports
NetworkPorts
