4T Coal Fired Steam Boiler 4000Kg Coal Boiler Work For Plam Oil Mills

1. Boiler Introduction

The DZL/DZH new water-fire tube boiler is a new eco-friendly and energy-saving product co-developed by our company and famous Harbin institute of Technology and director of Beijing Institute of Light Boiler.
1. Boiler model:DZL/DZH
2. Boiler capacity:1-20ton/h
3. Pressure:1.0Mpa(10bar),1.25Mpa(13bar),1.6Mpa(16bar),2.5Mpa(25bar)
4. Steam temperature:184 °c,194°c, 204°c,226°c(As long as below 226°c,we can do it)
5. Fuel:coal,biomass
6. Structure:horizontal water-fire tube, single drum
7. Type:There are two types.One is DZL chain grate stoker automatic feeding fuel and removing dregs type. Another is DZH hand operated moving grate type which needs labour to feed fuel and remove the dregs.
8. Application:Medicine, chemical, light industry, textile, building material, cultivation, food and beverage, plastic foam, printing, dyeing and washing, rubber processing, paper products,wood processing, hotel, clothing and leather manufacturer etc.

2. Boiler parameter

3. Boiler Advantages

1. The output power remain constant
2. The boiler is heating up quickly and have high heat efficiency
3. Low original dust concentration,environmental protection and energy conservation
4. High quality of steam, high temperature steam output fit your production need
5. Strong water quality adaptability
6. Small size appearance, low investment in boiler room
7. Low running cost, safe and reliable (safety and reliability)
8. Short installation time, low installation cost

4. Boiler working features

1. Adopting automatic screw feeding, with reasonable second air technology and half gasification structure
helping fuel combusting completely, the thermal efficiency can reach more than 90%. Stable flame, producing steam cautiously.
2. Primordial dust emissions density is low:The volume of the coal-fired steam boiler is large and there is a dust separation device, so the primordial dust emissions density will be controlled much lower than the standard allowed.
3. Control system: Installing microcomputer to operate with one-button, people just set the process, and it can work automatically during the operating time. Once any abnormal situation to happen, stopping automatically with sound-light alarm, and pointing to the failure code, so it saves time to maintain.
4. Our protected device is safe and reliable. Selecting superior pressure controller, safety valve, low water alarm, overpressure alarm, over-temperature alarm, in order to make boilers operate safely.
5. Heating fast:There are many spiral gas tubes in the boiler and almost half of the coal fired steam boiler shell can be heated, so the temperature can up soon.
6. It is simple to clean slag only after burning completing.

5. Boiler Application Field

1. Food industry
2. Wood processing industry
3. Garment Factory
4. Chemical Industry
5. Rubber industry
6. Packaging industry
7. Rice mill
8. Dye industry

9. Animal food processing factory

10. Textile factory
