Safe Bagasse Fired Steam Boiler High Efficiency Steam Boiler 8 Ton/H Capacity
Safe Bagasse Fired Steam Boiler High Efficiency Steam Boiler 8 Ton/H Capacity
Specifications
Brand Name :
Yuanda
Model Number :
SZL
Certification :
ISO 9001:2008,CE,ASME
Place of Origin :
Henan,China
MOQ :
1 set
Price :
Discussed.
Payment Terms :
D/A, D/P, T/T, L/C, Western Union
Supply Ability :
100 sets per month
Delivery Time :
15-25 days after payment
Packaging Details :
Nude packaging for boiler main part and wood box packaging for boiler accessories.
Product name :
Safe and Green Biofuel Biomass Sawdust Burner Bagasse Fired Steam Boiler
Capacity :
8 ton/h
Rated steam pressure :
15bar, 16bar, 20bar
Weight :
3 ton - 40 ton
Fuel consumption :
low cost
Usage :
Industrial generation
Quality :
Strict quality system
Material :
Q345R
Description

Safe and Green Biofuel Biomass Sawdust Burner Bagasse Fired Steam Boiler


Yuanda offering wide range of SZL Bagasse Fired Steam Boiler to our valuable clients. These are available in different size and shape. These are made from high quality raw material. Our range of SZL boiler offer are known for features like commercially clean internal and external heat transfer surfaces, durability.


SZL Bagasse Fired Steam Boiler that Yuanda engineers designed this biomass fired boiler,can be provide by ASME, IBR, GB,CE etc certificate standards, and optimized its components according to the needs of customer (like burning palm kernel, palm fiber, types of coal fuel etc.). Yuanda Boiler Not only makes product meet environmental requirements, also bring customers a higher economic efficiency.

Accessories and Functions of some equipments

Descriptions Functions
Electrical cabinet Be responsible for electrical control of auxiliary machines, ensure the whole system work automatically and make operation convenient.
Feed water pump & water circulating pump Put water into boiler and promote hot water circulation.Compact structure,low power consumption,low failure rate
Automatic water softener Remove Mg+,Ca+ in the water and improve water quality. Prevent hurt to boiler tube,entend the boiler using life time.
Economizer Heat inlet water and reduce exhausted gas temperature, which increase boiler efficiency and is good for environment
Steam header Distribute steam to different directions.Used for distributing the steam to each pipe of user's workshop
Forced draught fan Blow clean air into the boiler and promote exhauted gas out, ensure the air circulation of the whole system.
Dust collector Remove the dust and ash in exhausted gas to protect envrionment and reduce polutions.
Gas flue and Chimney Provide channels for exhausted gas flow.
Fuel feeding
Grate speed adjustor Regulate the suitable speed of chian grate according to the combustion situation.
Slag remover/ slag extractor Extract slags mechanically and save labour cost.
Induced draught fan Blow clean air into the boiler and promote exhauted gas out, ensure the air circulation of the whole system.
Safety Valves It will work automatically when the working pressure is over high to protect the whole system
Pressure Gauge Show the working pressure of the boiler
Check Valves Connect pipes to ensure water not to flow backwards

Safe Bagasse Fired Steam Boiler High Efficiency Steam Boiler 8 Ton/H Capacity

Safe Bagasse Fired Steam Boiler High Efficiency Steam Boiler 8 Ton/H Capacity
