High Efficiency Fire Tube Steam Boiler Safety Control Energy Saving For Central Heating
High Efficiency Fire Tube Steam Boiler Safety Control Energy Saving For Central Heating
Specifications
Brand Name :
Yuanda Boiler
Model Number :
WNS
Certification :
ISO9001,CE,ASME
Place of Origin :
Henan,China
MOQ :
1
Price :
Be negotiated
Payment Terms :
D/A, D/P, T/T, L/C, Western Union, MoneyGram
Supply Ability :
1000 sets per year
Delivery Time :
15-25 working days after payment
Packaging Details :
Nude packaging for boiler main part and wooden box packaging for boiler accessories
Structure :
fire tube
Design fuel :
city gas,natural gas
Rated capacity :
0.5 ton - 20 ton
Boiler color :
Customized
Boiler application :
Textile industry
Boiler warranty :
2 year
Boiler working life :
more than 20 years
Quality control :
safety control system
Fuel consumption :
Energy saving and low cost
Description

High Efficiency WNS Gas Powered Biogas Fire Tube Steam Boiler for Central Heating

Introduction of WNS fire tube steam boiler

WNS series fire tube steam boiler is horizontal three pass fire tube wet back full automatic steam boiler. It normally suitable for 500kg to 20ton/h capacity, use all kinds of gas and oil fuels,such as natural gas, lpg,lng,cng,city gas,biogas, diesel oil,heavy oil.

1. Model:WNS
2. Capacity:500kg/h-20ton/h
3. Design pressure:1.0Mpa(10bar), 1.25Mpa(13bar), 1.6Mpa(16bar),2.5Mpa(25bar)
4. Stem temperature:below 224 degree
5. Design fuel:natural gas, lpg,lng,cng,city gas,biogas, diesel oil,heavy oil
6. Structure: three pass fire tube wet back

Technical parameter of fire tube steam boiler

Boiler model Rated capacity Rated pressure Rated Feed temp. Rated Steam temp. Fuel consumption Thermal efficiency
Light oil Heavy oil Natural gas City gas
t/h Mpa ℃ ℃ kg/h kg/h m3/h m3/h %
WNS1-1.0-Y(Q) 1 1 20 184 65.5 67.3 84.2 176 91
WNS 2-1.25- Y(Q) 2 1.25 20 194 129.6 132.2 165 346 92
WNS3-1.25-Y(Q) 3 1.25 20 194 192 195 250 510 92.1
WNS4-1.25- Y(Q) 4 1.25 20 194 256 261.9 323.6 682 93
WNS5-1.25- Y(Q) 5 1.25 20 194 318 322 386 87 93
WNS6-1.25- Y(Q) 6 1.25 20 194 380 390.6 450 1020 93.2
WNS8-1.25- Y(Q) 8 1.25 105 194 503 517 642 1321 93.5
WNS10-1.25- Y(Q) 10 1.25 105 194 628 643 805 1654 93.5
WNS15-1.25- Y(Q) 15 1.25 105 194 940 965 1182 2417 93.5
WNS20-1.25- Y(Q) 20 1.25 105 194 1250 1301 1597 3299 93.5

High Efficiency Fire Tube Steam Boiler Safety Control Energy Saving For Central Heating

High Efficiency Fire Tube Steam Boiler Safety Control Energy Saving For Central Heating

Fire tube steam boiler application fields

Medicine, chemical, light industry, textile, building material, cultivation, food and beverage, plastic foam, printing, dyeing and washing, rubber processing, paper products,wood processing, hotel, clothing and leather manufacturer etc.

High Efficiency Fire Tube Steam Boiler Safety Control Energy Saving For Central Heating

Fire tube steam boiler running advantages

1. Convenient and clean working
2. Low cost and high thermal efficiency
3. Long service life and simple maintenance
4. Easy installation and easy operation work
5. Fast and pure steam production in short minutes
6. Environmental friendly and long using life span
7. Simple boiler structure design and easy maintenance

High Efficiency Fire Tube Steam Boiler Safety Control Energy Saving For Central Heating
