Galvanized Press Welded Steel Bar Grate Sheet Stainless
Galvanized Press Welded Steel Bar Grate Sheet Stainless
Galvanized Press Welded Steel Bar Grate Sheet Stainless
Galvanized Press Welded Steel Bar Grate Sheet Stainless
Specifications
Brand Name :
Zhuote
Model Number :
255/20/100
Certification :
ISO9001-2015
Place of Origin :
Hebei
MOQ :
10 piece
Price :
Can discuss
Payment Terms :
L/C, T/T
Supply Ability :
800 Square meters/day
Delivery Time :
5 - 8work days
Packaging Details :
Steel belt packaging
Application :
Floor, Walkway, platform, stair tread, bridge
Surface treatment :
Hot Dipped Galvanized
Product name :
Steel Stair Treads Grating
Color :
any color
Size :
Customized
Width :
600-1250mm, 70-600mm, 995mm
Description

Galvanized press welded steel grating sheet stainless steel tree grating

Description:
1) Bearing Bar (Load Bar) Specifications (mm):
The specification of plain type and serrated type bearing bar is 20 x 3 to 100 x 10;the specification of I-section type is 25 x 5 x 3, 32 x 5 x 3, 38 x 5 x 3, 40 x 5 x 3, 50 x 5 x 3, 50 x 7 x 4, 55 x 7 x 4, 60 x 7 x 4, 65 x 7 x 4, 70 x 7 x 4, 75 x 7 x 4, etc.
2) Bearing Bar Pitch (center to center):
12.5, 15,25, 30, 30.16, 32.5, 34, 40, 41.25, 45, 50, 60, 60.32, 80, 100 mm etc, also be according to client's requirement and 30, 40, 60mm are recommended, America standard is available
3) Cross Bar Pitch (center to center):
38, 50, 76, 100, 101.6mm etc, also be according to client's requirement and 50, 100mm are recommended, America standard is available.
4) Material:
Mild Steel (Low Carbon Steel) or Stainless Steel
5) Surface Treatment:
Untreated, Painting or Hot dip Galvanizing
6) Steel grating standards:
A) China: YB/T4001-1998
B) USA: ANSI/NAAMM (MBG531-88)
C) UK: BS4592-1987
D) Australia: AS1657-1985
E) Japan: JJS.

Drainage steel grating cover Drainage ditch material

Steel,Low carbon steel,stainless steel&Q235,A36,SS304,SS316L,

S235JR
Surface treatment Black, hot dipped galvanized, paint
Bearing bar width*thickness 25x3,25x4,30x3,30x4,30x5,32x5,40x5,50x5,.....75x10mm
Bearing bar pitch

12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 34.3, 35, 40, 41, 60mm.

US standard: 1"x3/16", 1 1/4"x3/16", 1 1/2"x3/16", 1"x 1/4",

1 1/4"x 1/4", 1 1/2"x 1/4" etc.
Bearing bar shape

Plain Style Steel Grating, Serrated Style Steel Grating and I

Bar Type Steel Grating.
Drainage steel grating cover drainage ditch standard

China: YB/T 4001.1-2007, USA: ANSI/NAAMM(MBG531-88),

UK: BS4592-1987, Australia: AS1657-1985, Japan: JJS.
Cross bar shape round,twisted,bar shape
Cross bar pitch 38,50,76,100,101.6mm
Galvanizing standard US: ASTM (A123), CN: GB/T13912, UK: BS729
Market distribution America45%,Europe26%,Middle east38%,Other place27%

Our Services

1.We supply the pictures to customers

2.Any inquiries will be repled within 12 hours

3.Peofessional manufacturer

4.High quality,resonable,competitive price,fast lead time.

5.Risk taking and responsibility is clear

6.we have our own factory

7.18years experience

8.good quality and competitive price

9.perfect team can supply best service

10.quickly reply and accurate quotation

11.Conveniently in transportation

Galvanized Press Welded Steel Bar Grate Sheet StainlessGalvanized Press Welded Steel Bar Grate Sheet Stainless

Galvanized Press Welded Steel Bar Grate Sheet Stainless

FAQ

Q: Are you a manufacture?

A: Yes, we have specialized in this field for more than 15 years.

Q:How do you look at your customers?

A:They are not only our customers, but also our partners, we will work together to develop, win-win cooperation.

Q:Do you sell products only?

A:We not only sell products, we also provide services, we have a comprehensive after-sales service system.

Q: Do you provide sample?

A: The samples are provided free, but the customer need to pay the postage.

After the customer place order, we will deduct the postage from the payment.

Q: How long would it take to produce a sample?

A: 3-5 days after receiving the postage or get the postage collect account.

Q: What information should i provide,if i want a lowest quotation?

A: The specification of products, such as size, color, package and quantity.

Q: What is the MOQ? How many sets can fit in one Container?

A: Minimum order quantity can be discussed. We calculate the number of products that a container can hold based on the data

Q: Do u know the deliver charge to my port or my country?

A: Yes, I have ship agent, will offer u the best vessel and charge.
