DN15-DIN600 Stainless Steel Pipe Fittings Flanges High Pressure Flange
DN15-DIN600 Stainless Steel Pipe Fittings Flanges High Pressure Flange
Specifications
Brand Name :
DN15-DIN600 High pressure flange
Model Number :
LJ-PF446
Certification :
ISO9001
Place of Origin :
China
MOQ :
100pcs
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
Annual output 50000 tons
Delivery Time :
Depends on the quantity of goods
Packaging Details :
Export standard packaging
Material :
Stainless Steel,SS304 SS316L
Connection :
Welding
Standard :
DIN,ANSI,ASTM,JIS,GB
Application :
Construction,Connect Pipes
Packing :
wooden case
Surface :
black/galvanized/polish
Description

Stainless Steel Flanges DN15-DIN600 High pressure flange

Description

High pressure flange is used for connecting pipes or equipment with pressure higher than 10MPa. At present, it mainly includes traditional high-pressure flange and high-pressure self tightening flange.

High pressure flange is a part that uses the plastic deformation of the sealing gasket (elliptical gasket, octagonal gasket, lens gasket, etc.) to achieve the sealing effect, and is connected to the pipe end to connect the pipe with the pipe. There are holes on the flange, and the two flanges are tightly connected by stud bolts.

Technical data sheet

Carbon Steel Pipe Fittings ASTM A234 carbon steel tee technical data sheet as below:

DN PM1.6MPa(16bar) PN2.5MPa(25bar)
external diameter Diameter of bolt hole center circle Bolt hole diameter Bolt thread quantity external diameter Diameter of bolt hole center circle Bolt hole diameter Bolt thread quantity
10 90 60 14 M12 4 90 60 14 M12 4
15 95 65 14 M12 4 95 65 14 M12 4
20 105 75 14 M12 4 105 75 14 M12 4
25 115 85 14 M12 4 115 85 14 M12 4
32 140 100 18 M16 4 140 100 18 M16 4
40 150 110 18 M16 4 150 110 18 M16 4
50 165 125 18 M16 4 165 125 18 M16 4
65 185 145 18 M16 4 185 145 18 M16 8
80 200 160 18 M16 4 200 160 18 M16 8
100 220 180 18 M16 4 235 190 22 M20 8
125 250 210 18 M16 8 270 220 26 M24 8
150 285 240 22 M20 8 300 250 26 M24 8
200 340 295 22 M20 8 360 310 26 M24 12
250 405 344 26 M24 12 425 370 30 M27 12
300 460 410 26 M24 12 485 430 30 M27 16

Characteristic

1. The sealing principle belongs to plastic deformation.

2. Connected by bolts.

3. Bolts should bear tensile force, temperature difference stress, bending moment, torque and many other external stresses.

4. The volume is huge, the weight is heavy, and the installation and positioning is very difficult.

5. The sealing performance is unstable, especially under harsh conditions (high temperature, high pressure and highly toxic medium), it is easy to leak, resulting in serious consequences.

Standard ANSI ANSI B16.5 ASME B16.47 series A/B
DIN DIN
EN EN1092-l:2002
Material ANSI CS A105/SA 105NSS 304/304L, 316/316L Alloy Steel: WHPY45/52/65/80
DIN CS RST37.2;S235JR SS 304/304L.316/316L
EN CS RST37.2;S235JR;C22.8SS 304/304L,316/316L
Pressure ANSI Class 150, 300, 600, 900, 1500 2500lbs
DIN PN6,PN10,PN16>PN25,PN40>PN64,PN100
EN PN6,PN10,PN16>PN25,PN40>PN64,PN100
Size ANSI 1/2" - 60”
DIN DN15-DN2000
EN DN15-DN2000

Package

DN15-DIN600 Stainless Steel Pipe Fittings Flanges High Pressure Flange

Delivery

DN15-DIN600 Stainless Steel Pipe Fittings Flanges High Pressure Flange

Product tags

dn15-dn2000 stainless steel pipe flange

,

ansi pipe flanges

,

pipe flange specification
