Multi Level Steel Structure Mezzanine Floor For Warehouse / Office
Multi Level Steel Structure Mezzanine Floor For Warehouse / Office
Multi Level Steel Structure Mezzanine Floor For Warehouse / Office
Multi Level Steel Structure Mezzanine Floor For Warehouse / Office
Specifications
Model Number :
T-steel mezzanine ZJ02
Certification :
AS4084
MOQ :
50m²
Price :
Negotiation
Payment Terms :
T/T, L/C
Supply Ability :
10000m²
Delivery Time :
15-30 Days
Packaging Details :
bubble foam
Material :
Steel Q235/Q345, Steel Q235/245
Finish :
Corrosion Protection
Name :
steel mezzanine floor
Structure :
Assembled
Color :
Orange,Blue,Black,Gray
Weight Capacity :
maximum 1000kg/m²
Length Span :
3000-6000mm/upright
Width Span :
Max 6000mm/upright
Description

Designed Multi-level Steel Structure Storage Industrial Mezzanine Floors

Description:

It's supported by racks,and a mezzanine is built on the upper layer,them the lower racks can store goods in order.The upper mezzanine has better load capacity,and the ground load capacity is relatively average.

It's widely used in these situations:warehouse is high;goo`ds are small;accessing goods by manpower,storage edmand is large.Besides,it can be applied to renovate old warehouse,to improve the warehouse space utilization.Single layer or multi-layer mezzanine can be designed according to the acrtual area and specifica requirements to make full use of space and save warehosue area.Normally it's 2-layer or 3-layer,and stairs,handrails and cargo elevators are equipped.

Multi Level Steel Structure Mezzanine Floor For Warehouse / Office

1. With composite racking structure, patented light-steel floor panel structure
2. Floor panel with large load capacity, low cost, quick construction
3. Can be designed into one layer or multi-layers according to actual situation
4. Ensures fullest space utilization
5. Provides direct access to all pallets
6. Surface: powder coated or galvanized and color optional
7. Can be designed according to clients' requirements

Futures

1. Doubly make use of ground space
2. Depending on the space of store, we can design the average span(3000-6000mm). The bearing limit can reach 1000kg/m2
3. Work in high efficiency combined with lift platform.
4.The advantage of the Mezzanine floor racking is safe, good looking& removable.

Advantages

Versatility and flexibility to meet any storage needs:

1. The most commonly used, of all storage systems for palletised goods. Low capital cost.

2. Easy installation and simple to adjust.

3. Compatible with most types of handling equipment.

4. Less storage density compared to other pallet racking systems.

5. Infinitely adjustable and offering a wide range of options and components.

6. Maximizes space use in any warehouse configuration while retaining optimum product accessibility.

7. quality garantee 5 years.

8. More than 100 workers enable us to garantee the delivery time , normal orders witin 20days.
Quotation requirement

A) The warehouse plan.

B) The size of Mezzanine.

C) The size of Mezzanine rack(length*width*height).
D) How many bays you want.
E) How many layers you want.
F) The loading capacity of each layer.
G) The RAL color you want.
Name Designed Multi-level Steel Structure Storage Industrial Mezzanine Floors
Certification AS4084standard

Details for common uprights

Upright Type(mm) Thickness(mm) Safety Factor Loading(KG)/m²

160*88

 5.5-8.0 1.5 500-1000
1.5

200*100

 5.5-8.0 1.5
1.5

250*125

 6.0-9.0 1.5
300*150 6.5-9.0 1.5
350*175 7.0-11

Multi Level Steel Structure Mezzanine Floor For Warehouse / Office
