Brand Name | KRIPAL |
Model Number | UKPN0/1/3/5 |
Type | Load Isolation Switch |
Number of poles | 3P,4P |
Current | 10A,16A,20A,25A,32A,40A,50A,63A,80A,100A,125A,150A |
Frequency | 50/60Hz |
Protection | IP65 |
Material | PC,Copper |
Standard | IEC/EN 60947-3, AS/NZS 3947 |
Identification | VDE,SEMKO,CE CERTIFICATE,CB TEST REPORT |
Warranty | One and a half years |
Advantage | Dustproof,Waterproof,Corrosion protection,Prevent the loss caused by long-term illumination,Safety,Low-energy,Easy setup |
Current(A) | Rated Voltage(V) | Model | |
3P | 4P | ||
10 | 230-440V | UKPN0-310 | UKPN0-410 |
16 | 230-440V | UKPN0-316 | UKPN0-416 |
20 | 230-440V | UKPN0-320 | UKPN0-420 |
20 | 230-440V | UKPN1-320 | UKPN1-420 |
25 | 230-440V | UKPN1-325 | UKPN1-425 |
32 | 230-440V | UKPN1-332 | UKPN1-432 |
32 | 230-440V | UKPN3-332 | UKPN3-432 |
40 | 230-440V | UKPN3-340 | UKPN3-440 |
50 | 230-440V | UKPN3-350 | UKPN3-450 |
63 | 230-440V | UKPN3-363 | UKPN3-463 |
63 | 230-440V | UKPN5-363 | UKPN5-463 |
80 | 230-440V | UKPN5-380 | UKPN5-480 |
100 | 230-440V | UKPN5-3100 | UKPN5-4100 |
125 | 230-440V | UKPN5-3125 | UKPN5-4125 |
150 | 230-440V | UKPN5-3150 | UKPN5-4150 |
Product Feature
1.Safe and reliable: terminals equipped with protective cover, VDE0106 standard, ensure the security of the fingers.
2. It has a variety of uses in industrial machinery and equipment. When used as a maintenance and insurance switch, for example, can be installed in part O 3 padlocks, in order to ensure the personal safety of users.
3. The application of flexible: 800 standard contact combination, almost unlimited combination switch.
4.It can be used reliably in lighting equipment,heating equipment and motors reliably,in addition,they also can switch the motor(AC-3) derectly,its high on-off ability can ensure the work reliability at frequently making and breaking.
5.Beautiful appearance,novel,simple,small size and function are the ideal choice among similar products.
Certification
Lead Time | Normally 20 days after received your fund, but mostly depends on your quantity |
Leading Port | Ningbo or Shanghai by sea or by air. If any other loading port please kindly advise and the extra inland transportation freight will be added accordingly. |
Trade Term | EXW, FOB, CIF as customer need |
Payment Term | T/T 30% as deposit,and 70% before delivery. |
Packaging | Neutral carton, or according to customer requirements |
Shipping | By Air, by sea, by express |
1. Your inquiry and problems related to our products or prices will be replied in 24 hours;
2. Strong production capacity and strict quality control system;
3. Well-trained and experienced staffs to answer all your inquires;
4. After-sale tracking service for all of our clients;
5. OEM & ODM are available; there is an our own mould tooling center in KRIPAL factory.
Our company
Zhejiang kripal Electric Co., Ltd. is a national high-tech enterprise specializing in R & D, production and sales. Our products mainly include: small, molded case circuit breakers, AC contactors, building electrical, outdoor waterproof, control components, industrial plugs and sockets, etc.
The company was founded in 1992, after 30 years of vigorous development, the existing plant area of more than 15000 square meters, more than 500 employees, including over 10 senior engineers, 30 professional technicists and 30 senior executives. The products have passed the certificate of UL,VDE,TUV, Kema,Semko,SAA,CE and CB test report,also ROHS international certification, and obtained the national 3C, ISO9001 quality certification.
The company adheres to the enterprise policy of "management, independent innovation, coordination and cooperation, brand supremacy" and abides by the promise of "virtue in the world". Practice the core values of "win-win cooperation with customers, common prosperity with employees, benefit creation for the company and harmonious contribution to society", and strive for the mission of "strive to realize the dream of professional electrical world brand".
We sincerely welcome new and old customers at home and abroad to contact us and create a better future.
