Specifications
Brand Name :
KRIPAL
Model Number :
UKF4 series
Certification :
VDE,SEMKO,CE CERTIFICATE,CB TEST REPORT
Place of Origin :
China
MOQ :
1000 pcs
Price :
negotiable
Payment Terms :
T/T, L/C, D/P
Supply Ability :
100000 pcs per month
Delivery Time :
20 days and depends on ordering quantity
Packaging Details :
Each unit packed in a individual box
Pole :
1P,2P
Rated current :
10A,16A,20A,35A
Material :
PC、Copper、
Protection degree :
IP66
Frequency :
50/60Hz
Standard :
IEC/EN60947,AS/NZS 3123:2005
Description

SAA IP66 Rotary Mini Isolator Switch 35A 2 Pole Weatherproof

Product Description

Waterproof isolating switch has super waterproof and dustproof function, can effectively prevent the entry of dust and oil, in case of rain or strong water spraying will not affect the performance of the product; At the same time, it has the characteristics of anti-corrosion, anti-ultraviolet, cold, high temperature, anti-aging, etc. It can solve your needs for safe electricity use in harsh outdoor environment such as rain, dust, freezing, high temperature and strong ultraviolet light. The weather-resistant isolating switch has a wide range of applications and is suitable for any outdoor application conditions.

Brand Name KRIPAL
Model Number UKF4
Type Weatherproof switch
Number of poles 1P,2P
Current 10A,16A,20A,35A
Frequency 50/60Hz
Protection IP66
Material PC,Copper
Standard IEC/EN60947,AS/NZS 3123:2005
Identification SAA,SEMKO,CE CERTIFICATE,CB TEST REPORT
Color Gray&White
Warranty One and a half years


Product Feature

1.The UKF4 Weather protected isolating switch is a robust range of switches suitable for virtually any external application.Included in the range are single,double pole switches from 10 to 35 Amps.The base mounted mechanism provides for easier termination and more wiring room.

2.Fixed Earth and Neutral connector bars with dual clamping screws per tunnel provide equal stripping lengths and secure clamping for all cables.Terminal bore provide equal stripping lengths and secure clamping for all cables.

3.A safety feature for mounting switches to metal structures is the insulating caps that cover base mounting screws to totally protect them from any live cables.

4.Each device is provided with a threaded conduit joint and threaded reducing pipe for connection to a 25mm or 20mm conduit and nut; Nuts must be installed to ensure IP ratings.

5.Impact resistant base and cover in almost all installation conditions can withstand violent impact between the base and cover is divided by a weather-resistant waterproof sealing ring.

6.For security,a 7mm diameter hole is provided for padlocking the lever in the OFF position.Deep moulsed barrieers protect the opetating lever from physical abuse or accidental switching.

7.Appearance color:the standard color of the switch is gray and white.

Product Application

Our products are widely used in metallurgical, chemical, power electronics, airports, railways, construction sites, mines, quarries, drainage treatment plants, automobile manufacturing, ports, terminals, shopping malls, hotels and other places. When used as a maintenance switch and safety switch, the "open" and "closed" positions should be clearly marked, and a padlock hole should be provided. The padlock can be installed in the "closed" part; if you want to lock it in the "open" position, you only need to lock one hole ; To ensure the safety of users.
