10.4 Inch 1024X768 High Brightness Lcd Display 1000nits with Resistive Touch Monitor
10.4 Inch 1024X768 High Brightness Lcd Display 1000nits with Resistive Touch Monitor
10.4 Inch 1024X768 High Brightness Lcd Display 1000nits with Resistive Touch Monitor
10.4 Inch 1024X768 High Brightness Lcd Display 1000nits with Resistive Touch Monitor
Specifications
Brand Name :
Axnew
Model Number :
AXD-10OPN1P3-VTH5(VGA;DVI)
Certification :
CE FCC Rohs
Place of Origin :
China
MOQ :
10 Pieces
Price :
US$160-240/PCS
Payment Terms :
T/T, Paypal, Western Union
Supply Ability :
2500 pieces/month
Delivery Time :
10 working days
Packaging Details :
5 Pcs /Carton with firm foam
Screen Size :
10.4 inch
Screen format :
4:3
Pixel :
1024x768
Contrast Ratio :
800:1
Brightness :
1000nits
Input signal :
VGA DVI-D
Touch type :
5 wire resistive touch with eeti chipset control
Power in :
DC12v /AC 110-240v
Description

10.4 Inch 1024X768 High Brightness Lcd Display 1000nits with Resistive Touch Monitor

10.4 Inch 1024X768 High Brightness Lcd Display 1000nits with Resistive Touch Monitor

Display Specifications
Display 10.4" Color TFT sunlight readable Monitor
Model Name AXD-10OPN1P3-VTH5
Active Display Area (mm) 211.2(H)x158.4(V)
Pixel Pitch (mm) 0.264(H)x0.264(V)
Resolution (Pixel) VGA (1024X768) 16.2M /6 bit + FRC
Brightness (CD/m^2) 1000cd/m^2
Contrast Ratio 800:1
Viewing Angle (CR >=10) 176/176
Power consumption 15.8W typical, normal operation
Touch Screen 5 wire resistive touch with EETI chipset controller
OSD Control On the back side
I/O Connectors 1x12v,1XVGA,DVI-D
Power Input DC 12V,4A 48W

Mechanical Specifications
Construction Steel open frame & sliver Color
Dimensions Subject to the updated drawings
Mounting Edge fixing holes,Vesa Mounting
Power source AC 100~240V/ 12V DC

Environment Specifications
Operating Temperature -20~70℃
Storage Temperature -30~80℃
Rating Facilitate installation of the demolition,solid portfolio

Ordering Information 10.4” 1024x768 high brightness open frame Monitor and power adapter for outdoors application

Features and Advantages


1.G industrial New perfect panels with wide temperature;High Brightness Monitor 1000nit wtih IPS technolgy
2. industrial control board supports the displays working 24 hours
3. Professional and industrial hardware and parts to guarantee its working normally in rough environment
4.Open frame design to protect the LCD screen
5. VGA DVI interfaces ;infrared touch with USB interface options
6. sunlight readable 10.4 inch open frame touch LCD for application control , advertising player ,campus and industrial terminals etc

Applications: Sunlight readable 1000nits 10.4 inch industrial LCD ; IR or resistive touch options , industrial controller board with VGA DVI input , used for Outdoor Automatic equipments, Outdoor Gaming, outdoor Advertising , vending embedded system etc.

10.4 Inch 1024X768 High Brightness Lcd Display 1000nits with Resistive Touch Monitor
