High Brightness 15 Inch Metal Industrial Touch Screen HMI With Isolated Power Supply
High Brightness 15 Inch Metal Industrial Touch Screen HMI With Isolated Power Supply
High Brightness 15 Inch Metal Industrial Touch Screen HMI With Isolated Power Supply
High Brightness 15 Inch Metal Industrial Touch Screen HMI With Isolated Power Supply
High Brightness 15 Inch Metal Industrial Touch Screen HMI With Isolated Power Supply
High Brightness 15 Inch Metal Industrial Touch Screen HMI With Isolated Power Supply
High Brightness 15 Inch Metal Industrial Touch Screen HMI With Isolated Power Supply
High Brightness 15 Inch Metal Industrial Touch Screen HMI With Isolated Power Supply
Specifications
Brand Name :
FLEXEM
Model Number :
FE4150X-B
Certification :
CE
Place of Origin :
ShenZhen
MOQ :
Negotiable
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
5000 pcs/week
Delivery Time :
1-7 business days after payment confirmed
Packaging Details :
Carton
Display :
15" 4:3 TFT LCD
Resolution :
1024×768
Power Protection :
Isolated power supply,Protected from thunderstrike and surging
Operating Temperature :
-20~70℃
Shell Material :
Front cover made by aluminum.and the surface with hard oxide treatment:The back cover is made of galavanized sheet,and the surface is with dry spray treatment
Dimension :
394mm×297mm×48..3mm
Description

400cd/㎡ high brightness Isolated power supply 15 inch metal HMI without logo

* Aluminum enclosure, low cost, high reliability.
* The main board is with spray coating treatment, adapt to harsh industrial environment.
* High resolution, high brightness, LED backlight.
* Totally new configuration software, rich gallery and powerful function.

Colors 24-bit Color
Ethernet 10M/100M
USB Port USB Host 2.0*1 ,USB Device2.0*1
Brightness 400cd/㎡
SD Card Supporting
Input Power DC 24V, Input Range:DC 18V~28V

1.Power Terminals
Pin1 DC24V High Brightness 15 Inch Metal Industrial Touch Screen HMI With Isolated Power Supply
Pin2 0V
Pin3 FG
2.COM1/COM3
Pin1 Rx-(B) High Brightness 15 Inch Metal Industrial Touch Screen HMI With Isolated Power Supply
Pin2 RxD_PLC (COM1 RS232)
Pin3 TxD_PLC (COM1 RS232)
Pin4 Tx-
Pin5 GND
Pin6 Rx+(A)
Pin7 RxD_PLC(COM3 RS232)
Pin8 TXD_PLC(COM3 RS232)
Pin9 Tx+
3.COM2/COM4
Pin1 Rx-(B) High Brightness 15 Inch Metal Industrial Touch Screen HMI With Isolated Power Supply
Pin2 RxD_PLC (COM2 RS232)
Pin3 TxD_PLC (COM2 RS232)
Pin4 Tx-
Pin5 GND
Pin6 Rx+(A)
Pin7 RxD_PLC(COM4 RS232)
Pin8 TXD_PLC(COM4 RS232)
Pin9 Tx+

Advantage:

1. More than 10 Years' Experiece in Drivers Manufacturing capacitive industrial mini hmi : the complete industry chain: the strong R&D team, the powerful supply capacity, the prefect system of freight of forwarding, and the frst-class pre-sale service in any problem in operating hmi .

2. Customization Production: size, model, package of capacitive hmi can be per customers' request.

3. Realizablw Quality: professional design team, strict QC system and strong transportation cooperation.

4. First-class Pre and After Service: we ensure the well processing of the practice of our industrial mini hmi for customers.
