Full HD 7 Inch Resistive Touchscreen HMI 800×480 Resolution Supporting SD Card
Full HD 7 Inch Resistive Touchscreen HMI 800×480 Resolution Supporting SD Card
Specifications
Brand Name :
FLEXEM
Model Number :
FE4070C-C
Certification :
CE
Place of Origin :
Shenzhen
MOQ :
1pc
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
5000 pcs/week
Delivery Time :
1-7 business days after payment confirmed
Packaging Details :
Carton
Display :
7'' TFT LCD
Resolution :
800×480
Colors :
24-bit Colors
Brightness :
360 cd/m²
Operating Temperature :
0～50℃
Shell Material :
ABS+PC
Description

24-bit color economic resistive HMI 7 inch economic touch panel HMI

Description:

* 7" 800×480 TFT LCD.

* ABS+PC, plastic enclosure and with only 38mm thickness.

* Industrial Isolated Power Supply module, 4 Serial Ports.

* USB 2.0 Device Port and high-speed software downloading.

* SD Card supporting.

* The mainboard is with spray coating treatment, adapt to harsh industrial environment.

Specification:

USB Port 1 USB Host 2.0, 1 USB Device 2.0
Power Consumption < 10W
Power Down Allowed < 5ms
Shell Material ABS+PC
Weight About 650g

1.Power Terminals
Pin1 DC24V Full HD 7 Inch Resistive Touchscreen HMI 800×480 Resolution Supporting SD Card
Pin2 0V
Pin3 FG
2.COM1/COM3
Pin1 Rx-(B) Full HD 7 Inch Resistive Touchscreen HMI 800×480 Resolution Supporting SD Card
Pin2 RxD_PLC (COM1 RS232)
Pin3 TxD_PLC (COM1 RS232)
Pin4 Tx-
Pin5 GND
Pin6 Rx+(A)
Pin7 RxD_PLC(COM3 RS232)
Pin8 TXD_PLC(COM3 RS232)
Pin9 Tx+
