Circular Ultrasonic Vibrating Screen , Rotary Vibrating Sieve Small Size
Circular Ultrasonic Vibrating Screen , Rotary Vibrating Sieve Small Size
Circular Ultrasonic Vibrating Screen , Rotary Vibrating Sieve Small Size
Circular Ultrasonic Vibrating Screen , Rotary Vibrating Sieve Small Size
Circular Ultrasonic Vibrating Screen , Rotary Vibrating Sieve Small Size
Circular Ultrasonic Vibrating Screen , Rotary Vibrating Sieve Small Size
Specifications
Brand Name :
TECHANG
Model Number :
TCCZS
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
100 sets per month
Delivery Time :
10~15 working days
Packaging Details :
Wooden case
Name :
High Efficiency Cost-Effective Circular Ultrasonic Rotary Vibrating Sieve Small Vibration Screen
Layer :
1-5 Layers
Frequency :
1450rpm
Material :
Stainless steel
Dimension(l*w*h) :
As per model
Ultrasonic unit :
Avoid blocking
Diameter :
400-1200 mm
Mesh size :
＞100mesh
Description

High Efficiency Cost-Effective Circular Ultrasonic Rotary Vibrating Sieve Small Vibration Screen

Introduction

High Efficiency Cost-Effective Circular Ultrasonic Rotary Vibrating Sieve Small Vibration Screen is able to convert electric energy with 220V,50Hz or 110V,60Hz into high frequency electric energy with 18KHz and then puts it into ultrasonic energy exchanger to make it change into mechanical vibration with 18KHz and attains the purpose of high effciency sieve and cleaning mesh, which makes it easy to sieve the superfine powder. This system uses a low amplitude, high frequency ultrasonic vibrating wave(mechanical wave)on the sieve mesh by the traditional vibrating sieve to improve the sieving abilities of superfine powder.This product is suitable for the users who demand the high additional value and fine powder.

Circular Ultrasonic Vibrating Screen , Rotary Vibrating Sieve Small Size

Circular Ultrasonic Vibrating Screen , Rotary Vibrating Sieve Small Size

High Efficiency Cost-Effective Circular Ultrasonic Rotary Vibrating Sieve Small Vibration Screen is suitable to sieve power, which is light density, low humidity, easy adhesion or a static of the powder and super fine powder, and improve the sieving efficiency. It is widely used in carbonize silicon, alloy powder, tungsten powder, aluminum powder, rubbing powder etc. it can completely solve the difficult technology problems that other screening machines cannot solve.

Circular Ultrasonic Vibrating Screen , Rotary Vibrating Sieve Small Size

Working Principle

High Efficiency Cost-Effective Circular Ultrasonic Rotary Vibrating Sieve Small Vibration Screen source through the transducer into longitudinal oscillation of high frequency sine form, those sasser spread to reasonator, and generate resonance, then vibration evenly transmitted to the screen surface by the resonator.Raw material doing low-frequency Three-D vibration, while ultrasonic vibrations, can prevent clogging screen mesh, but also improve the capacity and accuracy of screening.

Technical data

Model Effective diameter
(mm)		 Effective area
(m2)		 Mesh size
(mesh)		 Layers Power
(kw)
CZS600 φ540 0.2289 100~500 1~5 0.37
CZS800 φ730 0.4183 0.55
CZS1000 φ900 0.6359 1.1
CZS1200 φ1100 0.9499 1.1
CZS1500 φ1400 1.5386 1~4 1.5
CZS1800 φ1710 2.2687 1~3 3
CZS2000 φ1910 2.7922 1~3 3

Product features


1. Specialized technology for different materials, such as granularity, density and particle shape, to be screened and developed and produced;
2. Solved the problem of the sieving of strong adsorption, free huddle, strong stickiness, high static, high density, ultrafine powder, etc.
3. The accuracy of the sieve can be increased by more than 80% and the output is increased by 2-5 times.
4. Eliminates the pollution and wear caused by the conventional screening method to the powder, and greatly reduces the noise of the screening machine.
5. Maintain mesh size, stable screening accuracy, and reduce repeated screening times.
6. It is suitable for separating powders from 20 microns to 300 microns, especially for materials with difficult screening.

Circular Ultrasonic Vibrating Screen , Rotary Vibrating Sieve Small Size

Advantages


1. Fine sieving of sticky and difficult materials.
2. Saving time for cleaning screen.
3. Eliminating the pollution of bouncing balls to materials.
4. Keeping screen mesh size & stabilizing sieving precision.
5. disintegrating adhesive materials, reducing the coarse materials.
6. Decreasing sieving times.
