11.52m2 Rotary Vibrating Screen Machine For Powder Separator Grading
11.52m2 Rotary Vibrating Screen Machine For Powder Separator Grading
Specifications
Brand Name :
TECHANG
Model Number :
TCXZS
Certification :
Food Processing
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
50 sets/month
Delivery Time :
20 working days
Packaging Details :
Wooden case
Name :
Rotary vibrating screen machine for powder separator grading
Input size :
≤10 mm
Dimension(l*w*h) :
Variable
Screening mesh area :
1.62~11.52 m2
Customized :
Acceptable
Layer :
1-5
Mesh size :
0-500 mesh
Description

Rotary vibrating screen machine for powder separator grading

Product Discription

Rotary vibrating screen machine for powder separator grading is a high precision fine powder sieving machine. The fundamental principle of round separator is that the eccentric hammers installed on the top and bottom ends of motor changes the rotation motion of motor to horizontal, vertical and inclined three-dimensional motions, and then passes this motion to screen surface, achieving the purpose of classification, filtering and removal of impurities.

11.52m2 Rotary Vibrating Screen Machine For Powder Separator Grading

Application-Rotary vibrating screen machine for powder separator grading


1. Chemical industry: resin, pigment, cosmetic, coatings, Chinese medicine powder.
2. Food industry: sugar powder, starch, salt, rice noodle, milk powder, egg powder, sauce.
3. Medicinal industry: all kinds of medicine.

11.52m2 Rotary Vibrating Screen Machine For Powder Separator Grading

Advantages-Rotary vibrating screen machine for powder separator grading

1. Can be used with single or multilayer screen mesh.

2. Automatic discharge of materials, continuous operation.

3. No dead corner of parts, easy rinse thoroughly and disinfection.

4. High screening precision, high efficiency, suitable for any powder, grain and mucus materials.

Technical data-Rotary vibrating screen machine for powder separator grading

Model

Power

(kw)

Diameter

(mm)

 Layer

Mesh Size

(mesh)

Frequency

(rpm)
TCXZS400 0.37 360 1-3 1-500 1500
TCXZS600 0.55 560 1-3 1-500 1500
TCXZS800 0.75 760 1-3 1-500 1500
TCXZS1000 1.1 960 1-3 1-500 1500
TCXZS1200 1.5 1130 1-3 1-500 1500
TCXZS1500 2.2 1430 1-3 1-500 1500
TCXZS1800 2.2 1730 1-3 1-500 1500
TCXZS2000 3 1730 1-3 1-500 1500
