Seed Carbon Steel DZSF 960r/Min Linear Motion Vibrating Screen Vibro Screen
Seed Carbon Steel DZSF 960r/Min Linear Motion Vibrating Screen Vibro Screen
Seed Carbon Steel DZSF 960r/Min Linear Motion Vibrating Screen Vibro Screen
Seed Carbon Steel DZSF 960r/Min Linear Motion Vibrating Screen Vibro Screen
Specifications
Brand Name :
TECHANG
Model Number :
TCDZSF
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiatable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
50 sets per month
Delivery Time :
20~30 working days
Packaging Details :
Wooden case
Name :
Seed Carbon Steel DZSF Linear Vibrating Screen
Application :
Seed
Capacity :
50 KG~100 T/H
Frequency :
960 t/min
Angle of oscillation :
45~60 degree
Layer(s) :
1-8 layers
Amplitude :
6-8 mm
Customized :
Acceptable
Description

Seed Carbon Steel DZSF Linear Vibrating Screen

Introduction

Seed Carbon Steel DZSF Linear Vibrating Screen is a high precision fine powder screening machine.The fundamental principle of vibrating screen sifter is that the unbalanced weight dropper installed on the top and bottom ends of motor changes the rotation motion of motor to horizontal, vertical and inclined three-dimensional motions, and then passes this motion to screen surface, achieving the purpose of classification, filtering and removal of impurities.

Seed Carbon Steel DZSF 960r/Min Linear Motion Vibrating Screen Vibro Screen

Seed Carbon Steel DZSF 960r/Min Linear Motion Vibrating Screen Vibro Screen

Features

1. Low consumption with high yield and low cost.
2. Good sealing without dust flying.
3. Can be used for single or multi layer.

Technical data

The below table shows the detailed data of different models of Seed Carbon Steel DZSF Linear Vibrating Screen for your reference. And we will choose a suitable model according to your materials and application.

Model Size of screen surface Number of layers of screen Mesh size Number of vibration amplitude Motor power
DZSF520 500*2000 1-6 2-400 mesh 960r/min 4-8 2×0.4
DZSF825 800×2500 1-6 2×(0.4-0.75)
DZSF1020 1000×2000 1-6 2×(0.75-1.5)
DZSF1030 1000×3000 1-6 2×(0.75-1.5)
DZSF1230 1200×3000 1-6 2×(0.75-3)
DZSF1530 1500×3000 1-6 2×(0.75-3)
DZSF1540 1500×4000 1-6 2×(0.75-3)

Application

Seed Carbon Steel DZSF Linear Vibrating Screen is widely used in food industry, mining industry, chemical industry, medical industry, waste treatment, etc. Main functions are removing impurity, filtering, classification of material, solid-liquid separation, screening.
