Single Shaft Shredder For Plastic Film Bale , Plastic Film Bale Shredder For Sale , Jumbo Bags Shredding
Brief Introduction of Single Shaft For Plastic Film
Feature & Function:
1. Single shaft shredder has characters as follows: single shaft shredder properties as follows: strong, durable. It is suitable to recycle a variety of bulk solid materials, refractory materials, plastic containers and plastic barrels, plastic films, fibers, paper. Shredded particles can be small to 20mm according to different needs. We can provide all kinds of feed hopper; low speed rotary cutter in accordance with customer needs , which will be low noisy and energy saving.
2. Single shaft shredder consists of a knife disc and a static knife to complete shredding material. Cutter is composed of a base shaft and several shape quadrilateral knife block. The knife block has 4 blades, can be replacing the use of. The knife block along the axis of the base is in multiple rows into type V, and fixed with screws in the radical axis, rotated with the based shaft together, finally comprise a knife disc. The two static knife is fixed on the machine frame. The material is sent to the cutter by the horizontal hydraulic cylinder. The speed is stable and adjustable, and the propulsive force is large and uniform. It is applicable to the recovery of a variety of bulk solid materials, refractory materials, irregular plastic containers and plastic barrels, tubes, films, fibers, paper etc. Spindle speed is 45 ~ 100 rpm/min.
3. We can offer a variety of rotor configurations to suit different applications.Such as:High Performance Rotor,Hard Material Rotor and Soft and Film Rotor.
4. When customers choose the rotor, we can also offer different knives holder to suit different requirement. Such as:Welded Knife holders,Assembled Knife holders and CNC cutting knife holders.
Main Features of Single Shaft Shredder For Plastic Film Bale
1. Rugged Mechanical Design,Hardened steel knives and gears ,The blade base and blade on the rotary roller can be dis-assembly .it is easy to clean and maintenance. |
2. working in automatically condition,it equiped with hydralic pushing system ,The speed is smooth and adjustable,propulsion is large and uniform . |
3. With many sizes of screen available for choosing,so different final sizes are available |
4. Single shaft shredder is strong and durable. Suitable for recycling a variety of bulk solid materials |
5. Different cutters seaters design for meeting different crushing demands , The rotary blade adopt the V design, It can decrease the noise and decrease energy consumption. |
Specifications
型号(Model): | XRM1000S | XRM1000 |
电机功率(Motor Power): | 55kw | 75kw |
动刀数量(Qty of Rotor blades): | 42 | 56 |
定刀数量(Qty of Fixed blades): | 2pcs | 2ps |
刀片材质(Materials of blades): | Cr12MoV/SKDII/D2/DC53 | Cr12MoV/SKDII/D2/DC53 |
转速(Speed): | 50-80 rpm | 50-80 rpm |
进料口尺寸(feeding Size): | 1300*1500 mm | 1300*1500 mm |
主轴回转直径(Diameter of Rotor): | 400mm | 450mm |
撕碎室尺寸(shredding room size): | 1000*1000 mm | 1000*1000 mm |
液压站功率(Hydraulic motor power): | 5.5 kw | 5.5 kw |
油缸行程(Cylinder stroke): | 1000 mm | 1000 mm |
设备尺寸(Dimension L/W/H): | 3600*2400*2600 mm | 3600*2450*2600 mm |
设备重量(Weight): | 9300 kg | 9500 kg |
Single shaft shredder and plastic film shredding samples display
Quick details
1. Lead time - 65 working days
2. Payment Term - 30% advanced payment once upon signing the contract,70% balance payment before delivery.
3. Machine Installation
4. Our guarantee period is 12 months. Within the guarantee period the broken parts (excluding quick-wear parts) can be exchanged with our new parts if it is not caused by human factors. And technicians are available for solving big problems overseas(this situation never happened ). Beyond the guarantee period the broken parts dispatched are charged at cost price.
