Specifications
Brand Name :
CHENENG
Model Number :
MPF
Certification :
CE/ISO
Place of Origin :
China
MOQ :
1pcs
Price :
negotiation
Payment Terms :
L/C, T/T
Supply Ability :
10pcs per month
Delivery Time :
30 working days after received your payment
Packaging Details :
nude packing, bulk packed in wooden cases
Product Name :
Dissolved air flotation
Application :
Water treatment
Material :
CS or SS
Standard :
ISO
Working Capacity :
3-100m³/h
Structure :
Compact Connection
Description

DAF dissolved air flotation filtration for Meat industry , Poultry processing

Specifications:

Type
size

Treatment
capacity

Length
(mm)

Width
(mm)

Depth
(mm)

Pump power
consumption
(kw)

Skimmer power
consumption
(kw)

MPF-3

3m³/h

2800

800

1900

1.1

0.37

MPF-5

5 m³/h

3000

1000

1900

1.1

0.37

MPF-10

10 m³/h

4000

1200

2100

2.2

0.37

MPF-15

15 m³/h

4500

1500

2100

3.0

0.37

MPF-20

20 m³/h

4500

1800

2100

3.0

0.37

MPF-30

30m³/h

5500

2000

2100

4.0

0.37

MPF-40

40m³/h

6000

2200

2100

4.0

0.37

MPF-50

50m³/h

6000

2700

2100

4.0

0.37

MPF-60

60m³/h

7000

2800

2100

5.5

0.37

MPF-70

70m³/h

8000

3000

2100

5.5

0.55

MPF-80

80m³/h

9000

3200

2100

11

0.55

MPF-100

100 m³/h

9000

3600

2100

15

0.55


Description:
By means of innovative pump technology an increase of efficiency up to 80% has been realized e.g. in the dissolved air flotation (DAF) compared to traditional systems for industrial and municipal water and wastewater treatment applications. Specially designed open impellers for multiphase (DAF) pumps are sucking in air automatically - means no separate compressors and tanks required - operate as dynamic mixer with high shearing forces and increase pressure at the same time. This results in clearly reduced investment and operation costs for the benefit of system manufactures and the end users as well.
The multiphase pump dissolved air flotation system is a clarification process for the separation of solids, grease and oils. It works by using multiphase pump to mix water and air, then release it, producing a stream of micro-fine air bubbles that attach to solids and float them to the surface, where they can be removed by a surface scraping mechanism.

Applications:

1. Abattoirs

2. Cheese processing

3. Container washing

4. Dairies

5. Food processing

6. Fish processing

7. Metal removal

8. Meat industry

9. Poultry processing

10. Pulp& paper

11. Small goods

12. Tanneries

13. Vegetable industries

Competitive Advantage:

No air compressor

Compare to the traditional dissolved air flotation, no need for air compressor,

which will save cost, power consumption.

Integrated chemical

reaction tanks

This DAF system can be manufactured with any number of chemical reaction

tanks for upstream Ph control or coagulation. The reaction tank is constructed

in stainless steel, with a retention time to suit each application.

Skid-Mounted and

Pre-Teste

This DAF system is usually supplied as skid-mounted, pre-tested units to

simplify installation.

Bottom Sludge

Removal

For ease of cleaning, this DAF system are designed with a sloping base to
allow any settled solid to be drained as a option. On larger DAF systems our
unique hopper bottom is a cost-effective, proven method of automatically
removing solids.
