Water And Wastewater Treatment Daf Separator Achieve High Solids Capture Rate
Water And Wastewater Treatment Daf Separator Achieve High Solids Capture Rate
Specifications
Brand Name :
CHENENG
Model Number :
SOR
Certification :
CE/ISO
Place of Origin :
China
MOQ :
1pcs
Price :
negotiation
Payment Terms :
L/C, T/T
Supply Ability :
10pcs per month
Delivery Time :
30 working days after received your payment
Packaging Details :
nude packing, bulk packed in wooden cases
Product Name :
Dissolved Air Flotation
Application :
Water Treatment
Material :
CS Or SS
Standard :
ISO
Capacity :
1-100m³/h
advantage :
easily install
Description

Dissolved Air Flotation For process water and wastewater treatment, achieve high solids capture rate in advanced

Meet strict industry standards and facilitate compliance to environmental regulations.

DAF uses dissolved air flotation technology to separate fine dispersed particles from process water and wastewater to reach your desired specifications.

With the use of internal separation plates, high efficiency clarification is provided in modern, compact DAF designs. This allows for SUEZ's rectangular and vertical models to fit into existing installations where space is limited.

Features

With flow capacities up to 1800 m3/h (8000 usgpm), DAF units are offered in two different models: a horizontal rectangular PPM* model, and a vertical column-shaped Saturn* model configuration to suit particular site requirements.

Different stainless steel grades, such as 304L, 316L, Duplex 2205 and other corrosion-resistant materials are used for construction to fit process needs and contributes to long service life.

Compact configuration designs
Reduced installation and start-up cost by modular, preassembled units
Low operating costs with efficient polymer consumption
Minimal operator monitoring and maintenance required due to few moving parts and no submerged moving parts
Proven technology – over 700 references worldwide

Model Capacity(m³/h) Tank length(mm) Tank width(mm) Tank depth(mm) Pump(kw) Air compressor(kw) Skimmer(kw)
SOR-1 0.5-1m³/h 1500 955 1063 0.55 0.55 0.18
SOR-3 2-3m³/h 3000 2100 2300 0.75 0.55 0.37
SOR-5 3-5m³/h 3200 2300 2300 1.1 0.55 0.37
SOR-10 5-10m³/h 4200 2500 2500 1.5 0.75 0.37
SOR-15 10-15m³/h 4700 2800 2500 2.2 0.75 0.37
SOR-20 15-20m³/h 4700 3100 2500 2.2 0.75 0.37
SOR-30 20-30m³/h 5700 3400 2500 3.0 0.75 0.37
SOR-40 30-40m³/h 7200 3300 2500 5.5 0.75 0.37
SOR-50 40-50m³/h 7200 3800 2500 7.50 1.5 0.37
SOR-60 50-60m³/h 8200 3900 2500 7.50 1.5 0.37
SOR-70 60-70m³/h 9200 4100 2500 11.00 1.5 0.55
SOR-80 70-80m³/h 10200 4400 2500 11.00 1.5 0.55
SOR100 80-100m³/h 10200 4800 2500 15.00 2.2 0.55
