Industrial BAC Closed Cooling Tower 172m3/h Spray Water Flow Rate 32 Month Warranty
Industrial BAC Closed Cooling Tower 172m3/h Spray Water Flow Rate 32 Month Warranty
Industrial BAC Closed Cooling Tower 172m3/h Spray Water Flow Rate 32 Month Warranty
Industrial BAC Closed Cooling Tower 172m3/h Spray Water Flow Rate 32 Month Warranty
Industrial BAC Closed Cooling Tower 172m3/h Spray Water Flow Rate 32 Month Warranty
Industrial BAC Closed Cooling Tower 172m3/h Spray Water Flow Rate 32 Month Warranty
Industrial BAC Closed Cooling Tower 172m3/h Spray Water Flow Rate 32 Month Warranty
Industrial BAC Closed Cooling Tower 172m3/h Spray Water Flow Rate 32 Month Warranty
Specifications
Brand Name :
YCT/YAT/CLA/CLB/YKH
Model Number :
YANYE /JIANGFAN/BAOFENG
Certification :
ISO9001:2008/CTI ON SITE
Place of Origin :
SHANGHAI/WUXI
MOQ :
I UNIT
Price :
negotiation
Supply Ability :
340 unit /month
Delivery Time :
58 days
Packaging Details :
WITHOUT PACKAGE FOR CONTAINER OCEAN TRANSPORT
Cooling Coils :
High-quality seamless 316L SS Coils
Shell :
304 SS steel plate
Control Panel :
Schneider Brand
Power Supply :
380v/3p/50hz
Fan :
Motor grade: IP55; Insulation: F; Alum-alloy blades; Axial Flow
Temperature controller :
Standard
Spray Nozzles :
ABS basket nozzles of umbrella style
spare parts :
as per condition
Warranty period :
32 month
Electrical Brandname :
Simens
Description

Closed Cooling tower BAC Cooling tower Evapco Cooling tower Marley cooling tower Cooling system water cooling :

Item

FBN-300T Specifications
Heat Reject 1635kw
Nominal Flow Rate 300 m3/h
Work Flow Rate 235 m3/h
Fan Power 2×11kw
Wind Flow Rate 2×120000m3/h
Spray Pump Power 7.5kw
Spray Water Flow Rate 172m3/h
Spray Pump Raise 9.6m
Inlet/Outlet Diameter DN 200mm
Makeup Connection DN40 (Please specify adopted screw standards)
Bleed Line Diameter DN50 (Please specify adopted screw standards)
Net Weight 5150kg
Operate Weight 9500kg
Dimensions 5100×2300×4950mm

Structure

Wate cooling:When the fluid temperature is too high(surpassing setting temperature), the spray pump automatically spray the water on the pipe wall and form water film.Then the water film evaporats to absorb heat(latent heat of vaporization).Part of spray water becomes steam and is taken away by flowing air,the rest part becomes water drops and fall on the catch basin for next circulation The fluid inside the coil pipe is in closed loop and won’t lose theoretically.The consumption of spray water is only 0.1-0.2% of unit flow.

FEATURE

1,Cooling tower is mainly used for cooling in air conditioning system, frozen series, injection molding, leather, foam, power generation, steam turbine, aluminum processing, air compressors, industrial cooling water and other fields;

2,most used for air conditioning cooling, freezing, plastic chemical industry;

3, Closed circuit cooling tower have Attractive shape: Small dimension of shape, low height of tower, light weight of tower, and multiform layout in covering area.
