Class C Volumetric Multi Jet Water Meter Brass Housing For Sanitary Flow Meter DN15
Class C Volumetric Multi Jet Water Meter Brass Housing For Sanitary Flow Meter DN15
Class C Volumetric Multi Jet Water Meter Brass Housing For Sanitary Flow Meter DN15
Class C Volumetric Multi Jet Water Meter Brass Housing For Sanitary Flow Meter DN15
Specifications
Brand Name :
Iflow
Model Number :
LXH20
Certification :
ISO 4064, GB/T19001
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
T/T, L/C, D/P, Western Union
Supply Ability :
2200000 unit per year
Delivery Time :
4-6 weeks
Packaging Details :
carton + pallet
Type :
Volumetric water meter
Size :
DN20 (3/4")
Connect :
thread
Class :
Class C
R value :
160
House material :
brass / plastic
Upstream sensitivity :
U0
Downstream sensitivity :
D0
Description

Multi Jet Water Meter, also as volumetric water meter, brass meter housing for sanitary water meter DN15

Product Description

The wate rmeter housing are available with brass, plastic or stainless steel. This type of water meter, also called volumetric type water meter, which can be used for a remote reading transmission system as equipped with a built-in sensor..

Applications range:
These water meter are for record the total water volumetric flow meter in cubic, liter which pass through the closed pipe line, like water utilities, municipal water supply, etc.

Key Features

  • Volumetric rotary piston principle of measurement;
  • LXHY-15～20 is no location limitation for installation.
  • Accuracy is not to be affected wherever installed at a horizontal, vertical or inclined pipeline;
  • Register is sealed with a special liquid to keep a clear reading in long term service;
  • Mechanism use of high-quality material to ensure a stable characteristic;
  • Accurate measurement with conformity to ISO 4064 class C.

Note:

Technical data conform to International Standard ISO 4064.

Application:

Measuring the volume of cold portable water passing through the pipeline.

Data sheet

Model Size Class Q4 Q3 Q2 Q1 Min read Max read
m³/h m³/h m³/h
LXHY-15 15mm C 3 1.5 22.5 15 0.0001 9999
LXHY-20 20mm C 5 2.5 37.5 25 0.0001 9999
LXHY-25 25mm C 7.875 6.3 63 39.4 0.0001 9999


Flow curve

Class C Volumetric Multi Jet Water Meter Brass Housing For Sanitary Flow Meter DN15
Pressure curve
Class C Volumetric Multi Jet Water Meter Brass Housing For Sanitary Flow Meter DN15
Competitive Advantage:

  • Compliance to international standards: ISO4064 / GBT778 / Q/320700JR05-2003
  • Strict process control
  • Advanced calibration equipment
  • Engineer team

Production line
Class C Volumetric Multi Jet Water Meter Brass Housing For Sanitary Flow Meter DN15
Meter box
Class C Volumetric Multi Jet Water Meter Brass Housing For Sanitary Flow Meter DN15
