Automotive 25PIN Engine Wiring Harness Modular connector 09140253001 And 09140253101
Connectror | Housing hood | Support frame | Termail | Gland | Notes |
09140073001
09140073101 | 6B , 19300061540 / 1541 | 09140060303 , mark A , F , 2 modules | 09320006104
09320006105
09320006107
09320006108
09320006204
09320006205
09320006207
09320006208
| M20 / 25 / 32 | 70A , |
6B , 19300060546 / 0547 | 09140060313,mark a . F , 2 modules | ||||
10B , 19300101520 / 1521 | 09140100303,mark A , F , 3 modules | M20 / M25 / M32 | 70A , | ||
10B , 1930010527 / 427 / 586 | 09140100313,mark a . F , 3 modules | ||||
16B , 19300161521 / 522 | 09140160303,mark A , F , 4 modules | M20 / M25 / M32 / M40 | 70A , | ||
16B , 19300160527 / 528 / 427 / 428 586 / 587 / 487 | 09140160313,mark a . F , 4 modules | ||||
24B , 19300241541 / 542 / 547 / 548 447 / 448 / 586 / 587 / 588 / 487 | 09140240303,mark A , F , 6 modules | M20 / M25 / M32 / M40 | 70A , | ||
24B , 19300241541 / 542 / 547 / 548 447 / 448 / 586 / 587 / 588 / 487 | 09140240313,mark a . F , 6 modules |
Categories | Connectors, Interconnects Heavy Duty Connectors - Inserts, Modules |
Manufacturer | HARTING |
Series | Han® CD |
Connector Type | Module without Contacts |
Gender | Male |
Pins | 3+4 |
Termination Style | Crimp |
Voltage Rating | 600V |
Contact Type | Han® C, Han® D |
Color | Gray |
Housing Material | Polycarbonate (PC) |
Temperature | -40°C ~ 125°C |
