Specifications
Brand Name :
ABC
Model Number :
ABC-MT-0012
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
500PCS/month
Delivery Time :
30days
Packaging Details :
Carton box
Speed(RPM) :
220 ~ 1060 rpm
Continuous Current(A) :
100mA~8000mA
Efficiency :
IE 2
Usage :
FAN, Cosmetic instrument
Type :
Brushless Motor
Torque :
2.1N.m ~ 22N.m
Construction :
Permanent Magnet
Commutation :
Brushless
Protect Feature :
Waterproof
Description

1000w 1500w 2000w Permanent Magnet Synchronous Motor DC Motor Industrial Fan

Product parameter:

Model No.
Phase
Rated voltage
(V)
Rated power
(W)
Rated torque
(N.m)
Rated speed
(RPM)
Speed range
(RPM)
BL190200-01
3 Phases
AC 380
50/60Hz
1050
9
1450±50
220-1450
BL190205-02
3 Phases
AC 380
50/60Hz
750
10
580±20
220-580
BL190215-01
3 Phases
AC 380
50/60Hz
1100
13
630±20
220-660
BL190230-01
3 Phases
AC 380
50/60Hz
1500
15.84
700±20
220-720
BL190250-01
3 Phases
AC 380
50/60Hz
2200
22.00
750±20
220-780
BL190190-01
3 Phases
AC 380
50/60Hz
370
2.7
960±20
220-1060
BL190190-01B-01
3 Phases
AC 380
50/60Hz
550
2.2
1000±20
220-1060
BL190190-02
3 Phases
AC 380
50/60Hz
1050
9
780±20
220-780

Product Features:

Comparison items
Permanent magnet EC motor fan
AC asynchronous motor fan
Compared Quantity
1 pc
1 pc
Size
1460*1460*580 mm
1460*1460*580 mm
Maximum air flow
39000 m³/h
39000 m³/h
Speed
560 r/min
560 r/min
Input power
0.75 kW/h
1.0 kW/h
Starting current
0.3A~1.9A soft start, stable start, small current impact, no impact on the power grid.
1.5A~2.5A does not start smoothly, and the current impact is large, which is a big impact on the transformer and the power grid.
Annual electricity consumption of one fan
(24H/day, 365days/year)
1*0.75*24*365=6570 KWH
1*1*24*365=8760 KWH

Picture Display:

2000w Industrial Electric Motors Permanent Magnet DC Motor Industrial Fan2000w Industrial Electric Motors Permanent Magnet DC Motor Industrial Fan2000w Industrial Electric Motors Permanent Magnet DC Motor Industrial Fan

Q1: Are you a factory
A1: Of course.


Q2.Do you have certificate?
A2:Our company has achieved ISO9001, CE certification.

Q3: How about the delivery time?
A3: Our production period is normally 10-20 days after receiving advance payment. For some standard model, we can delivery
immediately if we have goods in stock.

Q4: Can we print the LOGO on products?
A4: Yes, OEM is available with the permission of our customers.

Q5: What is your payment term?
A5: T/T or L/C, if you want other payment terms, please contact us.
