3000 tons Horizontal Standard Injection Plastic Molding Machine , Haijiang machinery
3000 tons Horizontal Standard Injection Plastic Molding Machine , Haijiang machinery
3000 tons Horizontal Standard Injection Plastic Molding Machine , Haijiang machinery
3000 tons Horizontal Standard Injection Plastic Molding Machine , Haijiang machinery
Specifications
Brand Name :
Taihong
Model Number :
HJF3000
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
1sets/month
Delivery Time :
60 days
Packaging Details :
Export Standard
injection weight :
26745~39953
clamp Tonnage :
30000
Toggle stroke :
2000
space between tie bars :
1900*1750
Machine Dimension :
22.00*5.50*5.00
pump motor power :
55+55+55+55
Machine weight :
220
Description

Industrial 3000 Tons Automatic Plastic Injection Molding Machine

Quick Detail:

Industrial Plastic Injection Molding Machine is for normal type plastic material injection, e.g. PC, PP, PE, Nylon, A.B.S.etc.This machine is mainly used to produce middle&big industrial parts, household appliances and other plastic products.

Competitive advantages:

+injection Units

High injection pressure , High injection speed

+HYDRAULIC SYSTEM

Fast respone, stable output

+Electronic Units

intelligent control unit

Main technical parameters

SPECIFICATION HJ-3000U
A B C
Screw diameter mm 180 210 220
Screw L/D Ratio L/D 24 24 22.9
Shot size(theoretical) cm³ 29390 40003 43904
Injection weight(PS) g 26745 36402 39953
Injection pressure Mpa 210 155 141
Injection rate g/s 1468 2000 2200
Screw Speed rpm 50
Clamp tonnage KN 30000
Opening stroke mm 2000
Space between the tie bars mm 1900*1750
Max.Mold Height mm 1900
Min.Mold Height mm 1000
Ejector stroke mm 450
Ejector tonnage KN 565
Max.pump pressure Mpa 16
Pump motor power KW 55+55+55+55
Heater power KW 177
Machine dimension(L*W*H) M 22.00*5.50*5.00
Machine weight T 220
Oil tank capacity L 4500

Characteristics

1. Adopts the imported control components, durable, safe, and low failure rate.

2. Use human-computer interface, simple and more visually oriented.

3. The machine uses machine electrical and air linkage, excellent effect of bottom sealing.

4. East to adjust different sizes of cartons, adjust quickly and easily, available for a wide range of cartons.

5. Low power consumption, simple and convenient operation, low noise.

6. Use tap to seal the cartoon bottom, protected from weather, sealing reliable.

Shipping and Payment

Product Name 500 Injection molding machine
Packing Export standard package
MOQ 1 set
FOB price Please contact for new price
Delivery time 60days
FOB port Ningbo
Payment terms T/T,L/C at sight
