Tubular Electric PTFE Immersion Heaters For Acid Heating And Corrosive Chemical Heating
Tubular Electric PTFE Immersion Heaters For Acid Heating And Corrosive Chemical Heating
Specifications
Brand Name :
Surplus
Model Number :
PTFE immersion Heater 21
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 PCS
Price :
Contact Us
Payment Terms :
TT, Paypal, Western Union
Supply Ability :
50 PC/Month
Delivery Time :
10-15 working days
Packaging Details :
Wooden Case or Carton Box
Name :
Tubular Electric PTFE Immersion Heaters For Acid Heating And Corrosive Chemical Heating
Supply voltage (V/Phase): :
110V-480V
Power(KW) :
1KW-36KW
Type of temperature control :
Overheat protection
Application :
Acid Heating And Corrosive Chemical Heating
Frame Material :
PTFE
Inside material :
SUS
Cable length :
2 meters/3meters/others
Description

Tubular Electric PTFE Immersion Heaters For Acid Heating And Corrosive Chemical Heating

PRODUCT DESCRIPTION

Excellent chemical resistance to aggressive acids.

  • FEATURES

    • PTFE sleeved 304 stainless elements inert to most solutions up to 212°F (100°C).

    • Low watt density design 10 watts/square inch (1.5w/cm²).

    • Vapor resistant, flame retardant polypropylene terminal enclosure with 3 ft (.9m) flexible PVC liquid tight conduit.

    • Grounded internal metal element and built in thermal protector. Replaceable P1 protector standard for solutions up to 180°F(82°C).

    • Certification: cULus. CE certified and CSA

  • SPECIFICATIONS

    • 3000 - 18000 watts

    • 120 to 600 volts (600 volts on 12,000 watts or lower only)

  • OPTIONS AVAILABLE (CONSULT FACTORY)

    • Resettable thermal protectors

    • Polypropylene guards (sold separately)

    • Custom configurations and lengths

    • Custom wire and conduit lengths

FLAT ASSEMBLY TYPE – PTFE Immersion Heater

  • Universal ‘all plastic’ model

  • Ideal for important powers (from 6kW)

  • Up to 48 kW

  • Ideal for large tanks

Universal model for all types of installation such as side of tank, bottom of tank with feet or on slidings.
Rigid structure ideal for important powers.

Assembly type F
On a plastic rod frame PVDF or PP.
Standard configuration : heating cable coated Teflon® FEP and PP or PVDF rod frame.
For use on the side or at the bottom of the tank.

Others Applications

Ultra-High-Purity Heating
Designed with Ultra-High-Purity processes in mind, Surplus delivers clean-room assembled, reliable heating and power solutions to fit specific needs.

Products For Ultra-High-Purity Heating

Inline Heater

Tubular Electric PTFE Immersion Heaters For Acid Heating And Corrosive Chemical Heating

PFA Inline Heater

Tubular Electric PTFE Immersion Heaters For Acid Heating And Corrosive Chemical Heating

Inline Chemical Heater

Tubular Electric PTFE Immersion Heaters For Acid Heating And Corrosive Chemical Heating

PTFE Tanks

We can serve you in the teflon lined welded tank, small teflon lined vessel, mixer PTFE lined vessel and more PTFE teflon lined tank below.
Material used : PTFE, PFA, FEP, ECTFE, PVDF etched or glass backing.

Can store acid or alkali
high temperature resistance
Can custom sizes or even install PFA outlet and PFA inlet

Tubular Electric PTFE Immersion Heaters For Acid Heating And Corrosive Chemical Heating

Tubular Electric PTFE Immersion Heaters For Acid Heating And Corrosive Chemical Heating

 Tubular Electric PTFE Immersion Heaters For Acid Heating And Corrosive Chemical Heating
Tubular Electric PTFE Immersion Heaters For Acid Heating And Corrosive Chemical Heating Tubular Electric PTFE Immersion Heaters For Acid Heating And Corrosive Chemical Heating Tubular Electric PTFE Immersion Heaters For Acid Heating And Corrosive Chemical Heating
Tubular Electric PTFE Immersion Heaters For Acid Heating And Corrosive Chemical Heating Tubular Electric PTFE Immersion Heaters For Acid Heating And Corrosive Chemical Heating Tubular Electric PTFE Immersion Heaters For Acid Heating And Corrosive Chemical Heating

Precious Metal Deposition
Engineered to meet the most stringent requirements, accurate and reliable Heaters in Precious Metals' Deposition reduce materials waste. Low ripple Power Supplies provide clean and smooth direct current (DC), precision results while also saving on materials.

Products For General Metal Finishing

MOTS SINGLE – BOTTOM, DERATED
Derated, low watt density, L-shaped, bottom, metal over the side Immersion Heater. Single or Three phase. Three phase. 500-6000 watts, 120-480 volts.

.Tubular Electric PTFE Immersion Heaters For Acid Heating And Corrosive Chemical Heating

MOTS TRIPLE – L SHAPED
L-shaped, bottom style metal over the side heater. Three phase. Single or three phase. 3000-36000 watts, 200-600 volts.

Tubular Electric PTFE Immersion Heaters For Acid Heating And Corrosive Chemical Heating
9HX SERIES
Low watt density, 9 element fluoropolymer (PTFE) sleeved 304 stainless elements inert to most solutions. Three phase. 3000-18000 watts, 208-600 volts.
Tubular Electric PTFE Immersion Heaters For Acid Heating And Corrosive Chemical Heating		 6HX SERIES
Low watt density, 6 element fluoropolymer (PTFE) sleeved 304 stainless elements inert to most solutions. Three phase. 2000-12000 watts, 208-600 volts.
Tubular Electric PTFE Immersion Heaters For Acid Heating And Corrosive Chemical Heating
