Screw Tension and Compression Mini Force Sensor IN-MT-034
Screw Tension and Compression Mini Force Sensor IN-MT-034
Specifications
Place of Origin :
China
Brand Name :
Innovation
Model Number :
IN-MT-034
MOQ :
1 pc
Price :
USD1-USD100
Payment Terms :
L/C, T/T
Supply Ability :
1000PCS/MONTH
Delivery Time :
7-15DAYS
Packaging Details :
CARTON
Description

Screw Tension and Compression Mini Force Sensor IN-MT-034

Mainly applied in tension and compression testing instruments,

automatic equipments and testing fields, such as insertion force test instruments,

riveting machine, welding machine, hot & cold lamination machine,

feeling tester for keyboard switch, and etc.

Screw Tension and Compression Mini Force Sensor IN-MT-034

Screw Tension and Compression Mini Force Sensor IN-MT-034

Capacity 50-1000kg Material Stainless Steel
Rated Output 1.5-2.0 mV/V Output Impedance 700±3Ω
Zero Balance ±2%F.S. Insulation ≥5000MΩ/100VDC
Non-linearity 0.5%F.S. Recommended Excitation 5-10V
Hysteresis 0.5%F.S. Maximum Excitation 15V
Repeatability 0.5%F.S. Compensated Temp Range -10~60ºC
(30)Creep (30min) 0.1%F.S. Operating Temp Range -20~80ºC
Temp Effect on Output 0.05%F.S./10ºC Safe Load Limit 120%
Temp Effect on Zero 0.05%F.S./10ºC Ultimate Load Limit 150%
Input Impedance 700±5Ω Cable Size φ4x 3m
Wire Connection Ex + : Red; Ex - : Black; Sig + : Green; Sig - : White
