S Type Tension Aluminum/Stainless Steel Load Cell IN-MS-002
S Type Tension Aluminum/Stainless Steel Load Cell IN-MS-002
Specifications
Place of Origin :
China Load Cell
Brand Name :
Innovation
Model Number :
IN-MS-002
MOQ :
10 pcs
Payment Terms :
L/C, T/T
Material :
Aluminum/Stainless Steel
Description

S Type Tension Aluminum/Stainless Steel Load Cell IN-MS-002

Force measurement in small space installation,such as feeling tester for keyboard switch,
compression force measurement for hot and cold lamination machine,
and grasping force measurement for robotic hands

S Type Tension Aluminum/Stainless Steel Load Cell IN-MS-002

Load Cell Dimensions:

S Type Tension Aluminum/Stainless Steel Load Cell IN-MS-002


​

RANGE A B C M Weight
100-500N 16 19.1 6 M4
200N-2KN 26 40 12 M8

RANGE A B C M D E Weight
5-30N 16 19.1 5 M3 6.7 16.5
50N 26 19.1 6 M4 7.5 16.5

Load Cell Parameters:

Capacity 5N-2KN Material Aluminum/Stainless Steel
Rated Output 2.0±10%mV/V Output Impedance 350±3Ω
Zero Balance ±2%F.S. Insulation ≥5000MΩ/100VDC
Non-linearity 0.05%F.S. Recommended Excitation 2.5-5V
Hysteresis 0.05%F.S. Maximum Excitation 10V
