Manual Power Stainless Steel Valves Ball Type Stainless Steel Flow Control Valve
Manual Power Stainless Steel Valves Ball Type Stainless Steel Flow Control Valve
Specifications
Place of Origin :
Zhejiang, China (Mainland)
Brand Name :
ZHENGAKNG
Model Number :
CC0010
Supply Ability :
10000 Piece/Pieces per Month
Packaging Details :
standard packing
MOQ :
100 Piece/Pieces
Material :
Stainless Steel
Temperature of Media :
Medium Temperature
Pressure :
Medium Pressure
Power :
Manual
Media :
Gas
Structure :
Ball
Standard or Nonstandard :
Standard
Port :
ningbo/shanghai
Description

Stainless steel one piece female threaded ball valve

Main accessory material

NO

Accessory name

Material

1

Sealing ring

PTFE

2

sphere body

SS316

3

Sealing gasket

PTFE

4

valve cover

SS316

5

valve body

CF8M

6

valve handle

SS316

7

thrust washer

PTFE

8

padding

PTFE

9

packing nut

SS304

10

gasket

SS304

11

handle nut

SS304

12

handle cover

plastic

13

handle

SS304


Main dimension

SIZE

1/4"

3/8"

1/2"

3/4"

1"

11/4"

11/2"

2"

D

5.0

7.0

9.2

12.5

15.0

20.0

24.5

32

L

40

45

58

60

72

78

83

100

H

35

37

43.5

47

50

57

69

74.5

E

64

70

90

90

103

103

127

127

WT(g)

55

95

165

250

405

625

850

1400

Main machinery specification:
model PN testing pressure working temperature medium
strength (water)Mpa sealing(water) air(Mpa) low pressure sealing(air)Mpa
J41W-16P(R) 1.6 2.4 1.8 0.6 ≤200 nitrose
J41W-25P(R) 2.5 3.8 2.8 0.6 ≤200 nitrose
J41W-40P(R) 4.0 6.0 4.4 0.6 ≤200 nitrose
J41W-64P(R) 6.4 9.6 7.0 0.6 ≤200 nitrose
