Toroidal Type Instrument Transformer Manufacturers With Magnetic Material
Toroidal Type Instrument Transformer Manufacturers With Magnetic Material
Toroidal Type Instrument Transformer Manufacturers With Magnetic Material
Toroidal Type Instrument Transformer Manufacturers With Magnetic Material
Specifications
Brand Name :
Chuangyin
Model Number :
LZZW5-17.5
Certification :
Kema,CE,SGS,TUV
Place of Origin :
ShenZhen
MOQ :
1set
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
36,000,00pcs per year
Delivery Time :
Within 7 days
Packaging Details :
Carton packing for one sets, one set including three piece with Components
Highest Vote :
Up to 110KV
Rated Insulation Level :
17.5/38/95KV
Installation Site :
Outdoor
Rated Frequency :
50/60HZ
usage :
Measuring Electric Capacity, Current
Magnetic :
Magnetic Material
Type :
Toroidal Type
Description

17.5kV Medium Current Transformer Single-Phase Epoxy Resin Type MV/LV/HV CT VT PT Current Usage Magnetic Material​


1. Product Introduction:

Epoxy resincasting insulation and fully enclosed support construction, encloses the primary & secondary windings and annular core in the epoxy resin casting body.
Be suitable for measuring electric capacity, current and protective relaying in
the power system of 17.5kV

Technical Data

1. Installation site: Outdoor
2, Rated frequency: 50/60Hz
3. Rated Insulation Level:17.5/38/95KV
4, Technical standard accords with: IEC 60044-1
IEC 61869-1&2

Specification:

Item Specification Unit Data
1 Um kV 17.5
2 Rated Insulation Level kV 17.5/38/95

Rated Transformation Ratio(A) Accuracy Classes Combination Rated Output(VA)
0.2(S) 0.2 0.5S 0.5

75-100/5A

 0.2S,0.2,0.5S,0.5

10

15

10

15

10

15

20

10

15

20
150/5A
200/5A
300/5A
400/5A
600/5A
800/5A
1000/5A
1200-1600/5A

Remarks: Upon request we are glad to offer transformers according to other standards or with non-standard technical specs.

Outline drawing

Toroidal Type Instrument Transformer Manufacturers With Magnetic Material
