16mm Anti Slip Hydraulic Dock Ramp , Dock Plate Leveler
16mm Anti Slip Hydraulic Dock Ramp , Dock Plate Leveler
Specifications
Brand Name :
DESEO
Model Number :
DL2600
Certification :
CE/ISO9001
Place of Origin :
CHINA
MOQ :
1 UNIT
Price :
USD 2000/UNIT
Payment Terms :
T/T
Supply Ability :
200 unit per month
Delivery Time :
7-20 days
Packaging Details :
plywood package
Control system :
Push Button
Capacity :
25000-40000LBS
Platform :
Anti-skid Checkered Plate
Material :
High-duty Steel Structure
Application :
Warehouse,Loading,Cargo handling auxiliary equipment,Logistic Industry
Product name :
security loading dock leveler
Description
Material Description
Upper Plate
8 mm thickness, anti-skate steel plate
Swinging Lip
Single 16 mm thickness, 400mm length
Shaft
28mm galvanized
Foot Guard
Single galvanized,1.5 mm thickness
Support Profile
L Steel Profile,4 mm thickness
Control box
IP65, Monitor can display using times and DTCS, split control system , emergency stop
Safety system
a)self-lockingb)lip emergency stop
Working Range
-300mm to 350mm
Bumpers
400 x 100 x 80mm
Loading Capacity
6000kg-15000kg

Hydraulic dock leveler

1."I"-beam reinforcement ribs design under the deck ,which make our dock leveller much stronger than the common box-shape design.

2.Downward adjustment can be either automatic design or pull-chain design .

3.Can be either two big cylinder for deck lifting or one big cylinder for deck lifting.

4..Totally sand-blasted and vanish-baked for maximum painting adherence.

5.Powerpack:Italy " Hydr-app" brand

6.Conform to Europe EN1398 safety standards. We have CE certificate.

7.We supply the full-range dock equipments including dock leveler,sectional door,dock shelter/seal,vehicle restraint and so on.We have catalogue,drawing,

photos and installation guide for all these products.So the biggest advantage of dealing with us is that we can provide a complete dock solution for your project in a professional way.

Specifications:

Technical Parameter Max Size 7Ft(L)*10mm(W)
Lifting height 300mm above the dock leveler
Down height 300mm below the dock leveler
Capacity 25000-40000LBS
Control Unit Control system Push Button
Driving System Hydraulic system High performance hydraulic system
Driving Unit Brand HaiPu Motor
Safety System Safe Equipment Free bumpers
Smart and safe design
Hold -down function
High volume hydraulic driving
Backing -wrenching pulling of chains
Sealing system Dock seal, dock shelter and vehicle restraint.
Curtain Color Grey, Green
Warranty 1 year Free warranty for the hydraulic lifting system

DESEO hydraulic dock levelers are innovative, technologically advanced and ensure maximum productivity in the most
demanding loading dock environments.

· Strong and reliable operation.

· Reduced maintenance cost.

16mm Anti Slip Hydraulic Dock Ramp , Dock Plate Leveler

16mm Anti Slip Hydraulic Dock Ramp , Dock Plate Leveler

16mm Anti Slip Hydraulic Dock Ramp , Dock Plate Leveler16mm Anti Slip Hydraulic Dock Ramp , Dock Plate Leveler
